1900XPC
رقم القطعة: KOMATSU-1900XPC
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
1900XPC
المواصفات
| Width (ft) | 26 ft. 5 in |
|---|---|
| Ground clearance (ft) | 2 ft. 2 in |
| Length (m) | 10.36 |
| Length (ft) | 34 |
| Width (m) | 8.05 |
| Ground clearance (m) | 0.66 |
| Nominal payload (metric tons) | 18 |
| Nominal payload (short tons) | 20 |
| Dipper capacity (m^3) | 11 |
| Dipper capacity (yd^3) | 14 |
| Production (MTPH) | 1 348 - 1 797 |
| Production (TPH) | 1,486 - 1,981 |
| Nominal dipper capacity* (yd^3) | 14 |
| Nominal dipper capacity* (m^3) | 10.7 |
| Range dipper capacity (yd^3) | 10 - 25 |
| Range dipper capacity (m^3) | 7.5 - 19.1 |
| Rated suspended load (st) | 41 |
| Rated suspended load (mt) | 37.2 |
| Nominal payload dipper capacity note | *Payload and dipper capacity are dependent on many factors. Contact Komatsu Mining for an analysis of your specific application. |
| Height over gantry (m) | 10.11 |
| Height over gantry (ft) | 33 ft. 2 in |
| Width of crawler shoes (mm) | 1 066 or 1 219 |
| Width of crawler shoes (in) | 42 or 48 |
| Width of crawlers 42 in (ft) | 22 |
| Width of crawlers 42 in (m) | 6.71 |
| Length of crawlers (m) | 7.62 |
| Length of crawlers (ft) | 25 |
| Height - ground to bottom of counterweight slabs (m) | 1.7 |
| Height - ground to bottom of counterweight slabs (ft) | 5 ft. 7 in |
| Height of cut (ft) | 42 ft. 6 in |
| Height of cut (m) | 13 |
| Radius of cut (ft) | 58 ft. 6 in |
| Radius of cut (m) | 17.8 |
| Dumping height* door open (ft) | 27 |
| Dumping height* door open (m) | 8.2 |
| Floor level radius (m) | 11.6 |
| Floor level radius (ft) | 38 |
| Tail swing radius (m) | 7 |
| Tail swing radius (ft) | 23 |
| Operator eye level (m) | 7.4 |
| Operator eye level (ft) | 24 ft. 3 in |
| Dumping height (footnote) | *Height shown with bail-type dipper. Heights will be greater than bail-less or compact-bail dippers. Actual dumping height can be greater than door clearance height. |
