2300XPC AC
رقم القطعة: KOMATSU-2300XPC-AC
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
2300XPC AC
المواصفات
| Swing | Two modular P&H planetary gear cases of proven design and a single piece forged swing gear transmit torque for fast cycle times.Spring-set air release disc brakes – one per motor.Splash lube filtration system. |
|---|---|
| Nominal payload (metric tons) | 45.4 |
| Nominal payload (short tons) | 50 |
| Production (MTPH) | 3365-4488 |
| Production (TPH) | 3710-4947 |
| Rated suspended load (st) | 106 |
| Rated suspended load (mt) | 96 |
| Nominal payload dipper capacity note | *Payload and dipper capacity are dependent on many factors. Contact Komatsu Mining for an analysis of your specific application. |
| Height of cut (ft) | 44 ft. 3 in |
| Height of cut (m) | 13.5 |
| Radius of cut (ft) | 70 |
| Radius of cut (m) | 21.3 |
| Dumping height* door open (ft) | 28 |
| Dumping height* door open (m) | 8.5 |
| Floor level radius (m) | 14.2 |
| Floor level radius (ft) | 46 ft. 7 in |
| Tail swing radius (m) | 10.1 |
| Tail swing radius (ft) | 33 |
| Operator eye level (m) | 7.9 |
| Operator eye level (ft) | 26 |
| Dumping height (footnote) | *Height shown with bail-type dipper. Heights will be greater than bail-less or compact-bail dippers. Actual dumping height can be greater than door clearance height. |
| Dipper capacity (m³) | 18 - 25 |
| Dipper capacity (yd³) | 24 - 33 |
| Crowd | Powerband V-belt drive between motor and gear case absorbs shock loads.First and second reduction gearing in enclosed gear case for reliable splash lubrication, ease of maintenance, and extended component life.Twin-leg dipper handle with torsion box and rack and pinion drive has inherent stability in the bank for optimal digging.Spring-set air release disc brake. |
| Nominal dipper capacity* (yd³) | 24 - 33 |
| Nominal dipper capacity* (m³) | 18.3 - 25.5 |
| Supply voltage | 4,160 or 7,200 V 3 Phase, 60 Hz5,000, 6,000 or 6,600 3 Phase, 50 Hz |
| Nominal dipper capacity SAE 2:1 (m³) | 18.3 - 25.5 |
| Supply transformer | (minimum) 2,750 kVA |
| Nominal dipper capacity SAE 2:1 (yd³) | 23.94-33.35 |
| Minimum short circuit VA available at shovel | 22 MVA |
| Optimum truck size (180 mt (200 st) truck shown) (st) | 120 - 240 |
| Supply voltage note | *Voltage per customer requirements |
| Optimum truck size (180 mt (200 st) truck shown) (mt) | 109 - 218 |
| Propel | Two rugged P&H planetary gear cases of proven design independently transmit torque to the drive sprockets, producing the tractive effort required for fast, efficient propel and positioning operations.P&H brand Delta drive system with heavy duty cast crawler shoes.Spring-set air release disc brakes – one per motor. |
