Worthington® VSN Reciprocating Pump

Name: Worthington® VSN Reciprocating Pump
Brand: Flowserve
SKU: flowserve-3466

رقم القطعة: flowserve-3466

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The VSN is a vertical septuplex positive displacement reciprocating pump with very high efficiency and is offered in a wide range of hydraulic, mechanical, and material options. Features and benefits: - Monoblock liquid ends for both oil & gas and general industrial services - Self-aligning plungers ensure proper concentricity within stuffing boxes - Many valve styles to suit all liquid types - Stuffing boxes outboard of cylinder allowing for more complex sealing and piping arrangements - Stuffing boxes individually fastened to liquid cylinder for ease of maintenance - Totally enclosed power frame is dust and oil tight eliminating atmospheric contamination - Cylindrical crossheads and guides maximize the load bearing area and reduce wear, keeping replacement costs to a minimum - Full pressure lubrication systems to ensure all bearing areas are protected and run smoothly

المواصفات

Brand line	Worthington
Standards	Manufacturer standard
Status	Aftermarket support only - no longer available for purchase
Size Range	216 mm (8.50") stroke, with 140 mm (5.51") to 200 mm (7.87") diameter plungers
Pressure Class Range	Pressures to 242 bar (3507psi)
Flows to	798 m3/h (3511 gpm)
Temperatures to	300 °C (572°F)
Pressures to	242 bar (3507 psi)
Sylinder	Forged steel, Stainless Steel
Plunger	420SS, 420SS WC coated
