SIHI® Boost CB Systems Dry Vacuum Pump

Flowserve

SIHI® Boost CB Systems Dry Vacuum Pump

رقم القطعة: flowserve-773

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The SIHI Boost CB-System delivers high-performance deep vacuum in an encapsulated, dual stage design combining the SIHI Boost with a liquid ring backing pump for demanding industrial applications. Its integrated configuration enables faster evacuation, lower power consumption and a compact footprint with contact-free, oil-free operation. Features and benefits: - Deliver rapid evacuation with high suction capacity and fast pump-down performance at lower total power consumption - Ensure contamination-free operation through oil-free vacuum technology with non-contacting components and no mechanical shaft seals - Process demanding gases confidently with proven hydrogen handling capability and liquid ring backing pump compatibility - Optimize space utilization with an encapsulated, integrated design engineered for compact installations - Enhance operational reliability through contact-free operation, electronic gear synchronization and pre-failure condition monitoring

المواصفات

Brand lineSIHI
Size RangeSizes from 3500 m³/h (2100 cfm) up to 8000 m³/h (4800 cfm) suction capacity
Operating ParametersUltimate pressure down to < 0.001 mbar ( 0.07 Torr) in combination with a dry screw backing pump
