Flowserve Circpac™ MD Specialty Seal with Circumferential Bushing

Name: Flowserve Circpac™ MD Specialty Seal with Circumferential Bushing
Brand: Flowserve
SKU: flowserve-449

رقم القطعة: flowserve-449

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Circpac MD seals are a segmented circumferential seal designed for fans, blowers, dryers, turbines, centrifuges and other rotating equipment. Circpac MD seals come packaged in a convenient split housing for easy installation. Standard designs consistently outperform packing, bushings, labyrinths, and felt seals with lower gas consumption over a wider range of operating conditions. Features and benefits: - Floating circumferential rings are hydraulically balanced with hydrodynamic surface topography to minimize wear at high speeds and pressures - Standard radially split seal housing enables installation without dismantling equipment or requiring equipment modifications - Multiple ring configurations are available for higher pressures, process venting or draining, inert gas purging, reduced emissions, and emergency backup - Companion inert gas support panels are available to provide adequate flow and pressure of nitrogen or other barrier gases to achieve near zero emissions

المواصفات

Brand line	Flowserve
Temperature	-40 to 593°C (-40 to 1100°F)
Speed	up to: 46 m/s (150 fps)
Sizes	35 to 457 mm (1.375 to 18.000 inches)
Pressure	vacuum to 6.9 bar (100 psi)
Single ring	Low pressures
Tandem rings	Process vent or drain
Double rings	Inert barrier gas injection
Triple rings	Inert barrier gas injection; Lower barrier gas consumption rate
Quadruple rings	High pressure; Multiple vent, drain, or barrier gas injection ports
