Flowserve A76, API plan 76 Pump Gas Panel

Name: Flowserve A76, API plan 76 Pump Gas Panel
Brand: Flowserve
SKU: flowserve-4830

رقم القطعة: flowserve-4830

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The Flowserve A76, API Plan 76, vent panel is fully compliant with API 682 4th edition and directs leakage from the containment seal cavity to the vapor collection system for fluids that do not condense at ambient temperature. It's available as an assemble to order (ATO) product with standardized components, providing the benefits of faster quotation and quicker delivery time. Features and benefits: - Flexible installation options: available with butt weld or socket weld connections - Easy system integration: vent connection via ½" NPT or ½" Class 600 flange - Improved operational safety: multiple pressure monitoring and alarm configurations - Built for durability: fully stainless steel construction - Standards ready design: engineered to ASME B31.3 and compliant with PED and CRN

المواصفات

Brand line	Flowserve
Standards	API Standard 682 (4th Edition); ASME B31.3; Pressure Equipment Directive (PED) 2014/68/EU; CRN Canada wide
Size Range	1/2 inch Schedule 80
Materials	316 Stainless-Steel
Pressure Class Range	Class 600
MAWP	1.025 psi @ 400°F (71 bar @ 204°C)
MDMT	-49°F / -45°C
