FBSGF Gas Engine Driven Self-Priming Pump FBSGF-8H

Franklin Electric

FBSGF Gas Engine Driven Self-Priming Pump FBSGF-8H

رقم القطعة: franklin-electric-90271108

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

These heavy-duty, gas engine, self-priming pumps are an ideal choice for water transfer applications and temporary irrigation. Features and benefits: - Volute: Cast iron rugged construction with tapped openings for priming, venting and draining - Impeller: Semi-open cast iron with “blind hole” for engine shaft protection - Mechanical Seal: Standard carbon/ceramic faces, FKM elastomers, 300 series stainless components - Engine: Industry recognized Briggs & Stratton, or Honda equipped with adjustable throttle controls - Mounting: Horizontal position - Irrigation - Construction - Mining - Commercial - Municipal - Light Industrial

المواصفات

MotorSurface
Protection [IP]Not Applicable
Stages1
Motor NEMA Frame Typenot applicable
Motor CoolingAir
RotationClockwise facing the shaft
Temperature Rating200 °F
Maximum Fluid Temperature200 °F
Pump Body MaterialCast Iron
ImpellerSemi-open
Impeller MaterialCast Iron
Motor Bracket MaterialCast Iron
Discharge MaterialCast Iron
SealMechanical Seal
Suction MaterialCast Iron
DischargeThreaded - FNPT
Discharge Diameter2 "
Product Weight with Pack65 lb
Carton Length17.69 "
Carton Width16.75 "
Carton Height16.63 "
Warranty Standard Time12 Months
ApplicationsIrrigation, Construction, Mining, Commercial, Municipal, Light Industrial
Item #90271108
ModelFBSGF-8H
SeriesFBSGF Gas Engine Driven Self-Priming Pump
Product familyFBSGF Gas Engine Driven Self-Priming Pump
Pump Length16.16 "
Seal MaterialCarbon/Ceramic, FKM, 300 series S.S.
Pump Height14.1 "
Pump Width13.25 "
Impeller Diameter6.44 "
SuctionThreaded - FNPT
Suction Diameter2 "
Engine Size - Driven Pumps (CC)118
Engine Brand For Driven PumpsHonda
Engine Type For Driven PumpsAir Cooled, 4 Stroke, OHV
