Monobloc Pump, KS-810+, 7.5 HP, Three Phase, 400 Volts, Size 150 mm x 150 mm
رقم القطعة: kirloskar-brothers-d12020750110
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Overview 7.5 Hp three-phase monobloc pumps comprise a flatter efficiency curve for efficient operation. These heavy-duty self-priming monobloc pumps can withstand voltage fluctuations ranging from 300 to 440 volts. Kirloskar monobloc pumps are perfectly suited for Cooling towers, Irrigation in horticulture & agriculture, Swimming pool application, Water transfer and circulation, Air conditioning and refrigeration systems, etc. Key Features Flatter Efficiency Curve - Minimum variations in efficiency during entire operating range increases the utility of pump set for variable conditions Wide Voltage Design - The motor is designed to withstand wide voltage variation from 300 to 440 volts and reduces motor burning in case of low/high voltage Designed to Prevent Overloading - Lesser chances of motor burning as it does not get overloaded even if the pump is operated at a head lower than recommended, thus ensuring substantial cost saving due to low maintenance and breakdown Replaceable Wearing Parts - All wearing parts within the pumps are easily accessible and replaceable which facilitates ease of maintenance thereby extending the life of the pump Dynamically Balanced Rotating Parts - Minimum vibration protects the components from damage during the operation, thus ensuring consistent performance as concentricity is maintained CED Coated Impeller - Resistance to corrosion leading to longer life Automatic Air Release - Automatically releases air when the pump starts ensuring swifter and smoother operations, thus eliminating the necessity of operating air release cock
المواصفات
| Product Series | KS |
|---|---|
| Pump Model | KS-810+ |
| Pump Type (Installation) | Surface |
| Pump Type (Application) | Monobloc |
| Power (In HP) | 07.50 |
| Phase | 3 |
| Rated Voltage (Volts) | 400 |
| Frequency (in Hz) | 50 |
| Speed (rpm) | 1420 |
| Head Minimum (in m) | 5 |
| Head Maximum (in m) | 10 |
| Discharge Minimum | 41.00 |
| Discharge Maximum | 68.00 |
| Discharge unit | LPS |
| Suction Size (in mm) | 150 |
| Delivery Size (in mm) | 150 |
| Impeller | C.I. Gr. FG-200 OF IS:210 |
| Delivery Casing | C.I. Gr. FG-200 OF IS:210 |
| Motor Body | C.I. Gr. FG-200 OF IS:210 |
| Pump Shaft | C.S. 40C8 of IS:1570 Part-2 |
| Sealing | GLAND PACKED |
| Certification/Accreditation | NON-ISI |
| Warranty | 12 Months |
| Gross Weight (kg) | 191.0 |
| Net Contents | 1 Pumpset |
| Item Code | D12020750110 |
| Manufacturing location | Dewas, Madhya Pradesh |
| No. of Stages | 1 |
