Shallow Well Pump, LIFTER 125, 1.0 HP, 220 Volts, Single Phase, Size 25mm x 25mm

Kirloskar Brothers

Shallow Well Pump, LIFTER 125, 1.0 HP, 220 Volts, Single Phase, Size 25mm x 25mm

رقم القطعة: kirloskar-brothers-d11ag01001041038

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Overview LIFTER pumps comprise a thermal oveload protector for protection of motor from overloading. Suitable for the voltage range 160 to 240 volts (Single Phase) , and are thus perfectly suited for pumping water from shallow wells and tanks, domestic water supply, lifting water to apartments and houses, lawn sprinklers and water transfer. Features - Superior Performance - Up to 260% Higher discharge* as compared to competition in same class will lead to save up to 72% time to fill the 2000 liters overhead tank - High Suction Lift - The pump has suction lift capacity up to 8.5 meters with high head, allowing to pump water at high volumes for a variety of applications - High Grade F - Class Insulation - Robust design to withstand higher temperatures, which ensure the reliability, safety of equipment and enhances the life - Cathodic Electro Deposition (CED) Coating - CED is the latest coating technology for corrosion resistance with uniform coating, provides 5 times more protection over conventional painting, resulting in longer life. Hydraulic parts of Kirloskar pumps are CED coated - Wide Voltage Design - The motor is designed to withstand wide voltage variation from 160 to 240 volts and reduces motor burning in case of low/high voltage - High Efficiency and Energy Saving Design - Innovative design manufactured at state of art plant, delivers optimum efficiency at lower energy consumption resulting in significant cost savings - Enhanced Grip and Portability - A handle attached to the pump allows user to carry the pump anywhere, adding to its portability and convenience of use - Dynamically Balanced Rotating Parts - Minimum vibrations protect components from damages during the operations, consistent performance as concentricity is maintained - Easy Maintainable Designs - Easy maintainable design and better interchangeability of components so that pump can be serviced even at remote locations by semi-skilled technicians

المواصفات

Product SeriesLIFTER
Pump ModelLIFTER 125
Pump Type (Installation)Surface
Pump Type (Application)Shallow Well
Power (In HP)01.00
Phase1
Rated Voltage (Volts)220
Frequency (in Hz)50
Speed (rpm)2800
Head Minimum (in m)20
Head Maximum (in m)36
Discharge Minimum4600
Discharge Maximum1620
Discharge unitLPH
Suction Size (in mm)25
Delivery Size (in mm)25
ImpellerNORYL
Delivery CasingCAST IRON
Motor BodyALUMINUM
Pump ShaftCARBON STEEL
SealingMECH SEAL
Warranty12 Months
Gross Weight (kg)18.5
Net Contents1 Pumpset
Item CodeD11AG01001041038
No. of Stages1
Max Solid Size (in mm)Clear water
