PAS F88 JD-S 125HP
رقم القطعة: PASF88JDS125HP
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
PAS F88 JD-S 125HP
المواصفات
| Model | PAS F88 JD-S 125HP |
|---|---|
| Series | PAS |
| Vacuum pump Type | Diaphragm |
| Nominal Air Capacity | 50 cfm |
| Pump / Model | PA S F88 |
| Pump / Qmax | 3,750 USgpm |
| Pump / Hmax | 196 ft |
| Pump / Q max eff. | 2,900 USgpm |
| Pump / Eff. max | 80 % |
| Pump / Suction port | 8" Flange - ANSI class 150 |
| Pump / Delivery port | 8" Flange - ANSI class 150 |
| Pump / Impeller type | Semi Open, 2 vane |
| Pump / Impeller diameter | 12" |
| Pump / Solids handling | 3" |
| Coatings | Epoxy powder, average thickness of 3 MIL |
| Priming system | Material |
| Max vacuum | - 26.6 inHg |
| Speed | Various |
| Impeller Dia. | 12” / 315 mm |
| Style | Semi Open |
| Solids Dia. | 3" / 76 mm |
| Ns | 2000 rpm |
| Suction | 8" / 200 mm |
| Discharge | 8” / 200 mm |
| No. Vanes | 2 |
| Pump / Material | Engine system voltage |
| Pump / Casing | ASTM A536 ductile iron |
| Pump / Impeller | ASTM A536 ductile iron |
| Pump / Engine power rating | 125 HP |
| Control panel / Wear ring | ASTM A48 Class 20 grey iron |
| Control panel / Model | PW 1000 |
| Control panel / Wear plate | ASTM A48 Class 20 grey iron |
| Control panel / Shaft | AISI 630 stainless steel |
| Control panel / Mechanical Seal faces | Silicon carbide / Silicon carbide / VITON |
| Control panel / Elastomers | NBR + VITON |
| Control panel / Lubrication | Grease (bearings) |
| Control panel / Check Valve | ASTM A536 ductile iron + NBR rubber flap |
| Arrangement / Separator | Aluminium alloy |
| Drives / Fuel tank capacity | 90 USG |
| Drives / Fuel consumption | 6,1 US Gal/hr @2000 rpm @BEP |
| Drives / Dry weight | 5,283 lbs |
| Drives / Wet weight | 5,980 lbs |
