Eaton Moeller® series M22 emergency stop key-release button

Eaton

Eaton Moeller® series M22 emergency stop key-release button

رقم القطعة: 216514

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller® series M22 emergency stop key-release button

المواصفات

Product NameEaton Moeller® series M22 emergency stop key-release button
Catalog Number216514
Model CodeM22-PVS/K01
EAN4015082165147
Product Length/Depth115 mm
Product Height38 mm
Product Width38 mm
Product Weight0.073 kg
CertificationsCE CSA File No.: 012528 IEC/EN 60947-5 UL File No.: E29184 CSA CSA Class No.: 3211-03 UL UL 508 VDE 0660 CSA-C22.2 No. 14-05 CSA-C22.2 No. 94-91 IEC/EN 60947 UL Category Control No.: NKCR DNV GL LR
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.216514.html
Catalog NotesMax. number of contacts: four M22-(C)K01, …10 or two M22-(C)K02, …20, …11
Actuator functionKey-release
Actuator colorRed
ColorRed
DesignMushroom-shaped Classical
Actuating force50 N
Actuator diameter38 mm
IlluminationNon-illuminated
Unlocking methodKey-release
Knob travel5.7 mm
Actuator travel and actuation force (DIN EN 60947-5-1)4.8 mm
