XTran PSU 18-60 VDC for XT-2215-A nodes

Name: XTran PSU 18-60 VDC for XT-2215-A nodes
Brand: Belden
SKU: DCP-C

رقم القطعة: DCP-C

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

XTran PSU 18-60 VDC for XT-2215-A nodes

المواصفات

Name	V30912-A5020-A5
Overall Width	200.0 mm
Overall Height	44.5 mm
Overall Depth	285.8 mm
Weight	2.15 kg
Update and Revision	Revision Number: 0.27 Revision Date: 12-16-2025
Source URL	https://www.belden.com/products/industrial-networking-cybersecurity/mpls-networks/xtran/dcp-c
Belden Taxonomy Path	industrial-networking-cybersecurity > mpls-networks > xtran
Belden Category	industrial-networking-cybersecurity
Belden Subcategory	mpls-networks
Belden Sub-subcategory	xtran
Datasheet URL	https://catalog.belden.com/techdata/EN/DCP-C_techdata.pdf
Relative humidity (non-condensing)	0-95 %
Safety of industrial control equipment	EN 62368-1:2014
Accessories to Order Separately	PSU cable for DCP-C power supply: S30927-C16-A30
Operating Temperature Range	-20° to +55°C (-4° to 131°F)
Storage Temperature Range	-30° to +75°C (-22° to 167°F)
Product Category	Power Supplies
Transportation	EN 50121-4:2016 + A1:2019
Guarantee	Standard 1 year (extension possible)
Product Documentation	Available via Belden Solutions Portal site
Certificates	Available via Belden Solutions Portal site
Input Voltage	36-60 VDC (nominal 48 VDC, tolerance according to EN62368-1)
Basis Standard	CE, EN 55032:2015 + A11:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013 + A2 :2021, EN 55035:2017 + A11:2020, EN IEC 61000-6-1:2019, EN IEC 61000-6-2:2019, EN IEC 61000-6-3:2021, EN IEC 61000-6-4:2019
MTBF (MIL-HDBK 217F: Gb 25 ºC)	34 years with 2 units in a chassis, 900W Load
Power Supply Protection	Auto recoverable: Overtemperature / Overcurrent / Overvoltage; Input polarity protection
Power Supply Efficiency	At 48VDC (full load): 89 % (measured including fans)
Output Power	900W
Inrush Current Max	Cold start (full load) ETSI 300-132: < 30 Apk
Power Supply Connector	PC 5/ 3-GF-7,62 on front panel, SPC 5/ 3-STF-7,62 for cable
Node Compatibility	XT-2215-A
Power Utility	EN 61000-6-5:2015, EN 61850-3:2014 (§6.7), IEEE 1613-2009 (§4), IEEE1613-2013 (clause 5,7,8,9,10)
