725 Articulated Truck Bare Chassis

Name: 725 Articulated Truck Bare Chassis
Brand: Caterpillar
SKU: CAT-130660

رقم القطعة: CAT-130660

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

725 Articulated Truck Bare Chassis

Standard Wheel Base	3979 mm
Engine Model	Cat® C13B
Rated Payload	24 t
Gross Power - SAE J1995:2014	263 kW
Net Power - SAE J1349:2011	257 kW
Bore	130 mm
Stroke	157 mm
Displacement	12.5 l
Peak Engine Torque Gross (SAE J1995)	1941 N·m
Peak Engine Torque Speed	1200 r/min
Peak Engine Torque Net (SAE J1349)	1712 N·m
No Engine De-rating Required Below	3810 m
Lock to Lock	4.75 seconds at 60 rpm
Forward - 1	8 km/h
Forward - 2	15 km/h
Forward - 3	22 km/h
Turning Dimensions - Steer Angle - Left/Right	45 °
Forward - 4	34 km/h
Turning Dimensions - Aisle Width	5332 mm
Turning Dimensions - Clearance Radius	8075 mm
Forward - 5	47 km/h
Turning Dimensions - SAE Turning Radius	7470 mm
Turning Dimensions - Inside Radius	3879 mm
Forward - 6	55 km/h
Note	Dimensions are for machines equipped with 23.5R25 tires.
Reverse - 1	9 km/h
Fuel Tank	400 l
Cooling System	83 l
Hydraulic System	123 l
DEF Tank	34 l
Engine Crankcase	43 l
Transmission	47 l
Output Transfer Gear Box	25 l
Final Drive - Each	125 l
Brakes	ISO 3450:2011
Cab - FOPS	ISO 3449:2005 Level II
Cab - ROPS	ISO 3471:2008
Steering	ISO 5010:2019
Model	725 Bare Chassis
Product Page	https://www.cat.com/en_US/products/new/equipment/articulated-trucks/articulated-truck-bare-chassis/130660.html
Caterpillar Category	Articulated Truck Bare Chassis
Caterpillar Category Path	Products > Equipment > Articulated Trucks > Articulated Truck Bare Chassis > 725 Bare Chassis
Caterpillar Product Family	equipment
Caterpillar Product Page ID	130660
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20211214-0c0e1-13320
