904J-E36TA Industrial Diesel Engine

Perkins

904J-E36TA Industrial Diesel Engine

رقم القطعة: 1000024087

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

904J-E36TA Industrial Diesel Engine

المواصفات

Model904J-E36TA
Series904 Series
CategoryIndustrial
Power Rating / Maximum Power106 kW (142 hp)
Power Rating / Maximum Torque566 Nm @ 1500 rpm (417 lb-ft @ 1500 rpm)
Power Rating / Rated Speed2000-2400 rpm
Power Rating / Minimum Power55 kW (74 hp)
Emission Standards / EmissionsEU Stage V, U.S. EPA Tier 4 Final, Japan 2014
General / Number of Cylinders4
General / Bore98 mm (3.86 in)
General / Stroke120 mm (4.72 in)
General / Displacement3.6 l (220.9 in³)
General / Compression Ratio17.0:1
General / AspirationTurbocharged aftercooled (TA)
General / Combustion SystemDirect injection
General / Rotation from Flywheel EndAnti-clockwise
General / Cooling SystemLiquid
Engine Dimensions / Length667 mm (26.3 in)
Engine Dimensions / Width564 mm (22.2 in)
Engine Dimensions / Height787 mm (31 in)
Engine Dimensions / Dry Weight381 kg (840 lb)
General / AftertreatmentDOC+DPF or DOC+DPF+SCR
General / Total Lubricating Oil Capacity11.6 l (3.06 gal (US))
Engine Dimensions / Wet Weight421 kg (928 lb)
