John Deere

310 P-Tier Articulated Dump Truck

Name: 310 P-Tier Articulated Dump Truck
Brand: John Deere
SKU: JOHNDEERE-9461DW

رقم القطعة: JOHNDEERE-9461DW

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

310 P-Tier Articulated Dump Truck

المواصفات

and noise, Deere-designed	69-dB ultra-
Displacement	9.0 L (549 cu. in.)
Net Peak Power (ISO 9249)	264 kW (354 hp) at 1,900 rpm
Net Peak Torque (ISO 9249)	1621 Nm (1,195 lb.-ft.) at 1,500 rpm
Output Torque Split	32% front / 68% rear
Gear	1 6 km/h (3.7 mph) 6 km/h (3.7 mph)
Angle	45 deg. side to side
Struck	13.7 m (17.9 cu. yd.)
Heaped at 2:1 ISO 6483 Ratio	17.5 m (22.9 cu. yd.)
With Optional Tailgate	18.3 m (23.9 cu. yd.)
Maximum Dump Angle	70 deg.
Fuel Tank	496 L (131 gal.)
Diesel Exhaust Fluid (DEF) Tank	48 L (12.7 gal.)
Engine Oil With Filter	34 L (9.0 gal.)
Engine Coolant	52 L (13.7 gal.)
Transmission Fluid	60 L (15.9 gal.)
Hydraulic Reservoir	113.5 L (30.0 gal.)
Front	37 L (9.8 gal.)
Mid	37 L (9.8 gal.)
Rear	37 L (9.8 gal.)
Middle	5146 kg (11,345 lb.) 17 885 kg (39,430 lb.)
Total	22 847 kg (50,369 lb.) 50 972 kg (112,374 lb.)
Rated Payload	28 125 kg (62,005 lb.)
Dump-Body Liner (steel)	864 kg (1,905 lb.)
Tailgate	640 kg (1,411 lb.)
750/65R25 Tires	624 kg (1,376 lb.)
Inside	4.27 m (14 ft. 0 in.)
Outside	8.02 m (26 ft. 4 in.)
A Width With Mirrors in Operating	3.49 m (11 ft. 5 in.)
B Length	10.16 m (33 ft. 4 in.)
C Height	3.66 m (12 ft. 0 in.)
D Tread Width	2.28 m (7 ft. 6 in.) 2.28 m (7 ft. 6 in.)
E Width Over Tires	2.85 m (9 ft. 4 in.) 3.00 m (9 ft. 10 in.)
F Width Over Fenders	2.87 m (9 ft. 5 in.) 3.05 m (10 ft. 0 in.)
G Ground Clearance	0.49 m (19.4 in.)
H Dump Body Height, Dump Position	6.33 m (20 ft. 9 in.)
I Dump Body Side Rail Height	2.93 m (9 ft. 7 in.)
J Dump Body Dump Lip Height,	3.53 m (11 ft. 7 in.)
K Dump Body Ground Clearance, Dump	0.66 m (26.1 in.)
L Dump Body Length	5.59 m (18 ft. 4 in.)
M Rear Axle Centerline to Rear of Dump	1.56 m (5 ft. 1 in.)
N Mid Axle to Rear Axle Centerline	1.67 m (5 ft. 6 in.)
O Front Axle to Mid Axle Centerline	4.26 m (14 ft. 0 in.)
P Front Axle Centerline to Front of	2.67 m (8 ft. 9 in.)
Q Approach Angle	24 deg.
R Maximum Dump Angle	70 deg.
Overall Height (suspension lowered	3.59 m (11 ft. 9 in.)
Overall Length	10.16 m (33 ft. 4 in.)
Mirrors Folded In	3.07 m (10 ft. 1 in.) 3.12 m (10 ft. 3 in.)
Tailgate Installed	3.26 m (10 ft. 8 in.) 3.26 m (10 ft. 8 in.)
No derating is required up to	3050-m (10,000 ft.) altitude. Specifications and design subject to change without notice. Wherever applicable, specifications
earthmover tires, ROPS cab, full fuel tank, and	79-kg (175 lb.) operator.
Model	310 P-Tier
Base Code	9461DW
Division	construction-equipment
Product Family	articulated-dump-trucks
