John Deere

230 P-Tier Mid-Size Excavator

Name: 230 P-Tier Mid-Size Excavator
Brand: John Deere
SKU: JOHNDEERE-04Q0FF

رقم القطعة: JOHNDEERE-04Q0FF

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

230 P-Tier Mid-Size Excavator

المواصفات

Fuel Tank	390.0 L (103.0 gal.)
Diesel Exhaust Fluid (DEF) Tank	18.0 L (4.8 gal.)
Model	230 P-Tier
Base Code	04Q0FF
Division	construction-equipment
Product Family	excavators
With its	6.8L John Deere PowerTech™ PVS
Low	3.4 km/h (2.1 mph)
High	5.8 km/h (3.6 mph)
Implement	34.3 MPa (4,975 psi)
Travel	34.3 MPa (4,975 psi)
Swing	30.0 MPa (4,351 psi)
Boom (2)	125 mm (4.9 in.) 85 mm (3.3 in.) 1314 mm (51.7 in.)
Arm (1)	140 mm (5.5 in.) 100 mm (3.9 in.) 1510 mm (59.4 in.)
Bucket (1)	120 mm (4.7 in.) 80 mm (3.1 in.) 1060 mm (41.7 in.)
Speed	11.7 rpm
With full fuel tank;	79-kg (175 lb.) operator, 5.7-m (18 ft. 8 in.) boom, and 2.9-m (9 ft. 6 in.) arm
A Maximum Reach	9860 mm (32 ft. 4 in.)
A Maximum Reach at Ground Level	9680 mm (31 ft. 9 in.)
B Maximum Digging Depth	6650 mm (21 ft. 10 in.)
C Maximum Cutting Height	9470 mm (31 ft. 1 in.)
A Overall Length	9600 mm (31 ft. 6 in.)
B Overall Height	2980 mm (9 ft. 9 in.)
1.5 m (5 ft.)	3.0 m (10 ft.) 4.5 m (15 ft.) 6.0 m (20 ft.) 7.5 m (25 ft.) Maximum
With	1.0-m (1.3 cu. yd.) Bucket 24 900 kg (54,900 lb.) 44.4 kPa (6.4 psi) 5400 kg (11,900 lb.)
Arm,	2.9-m (9 ft. 6 in.) With Bucket 1070 kg (2,360 lb.)
Gross (SAE J1995 and ISO3046)	128 kW (172 hp) at 1,800 rpm
Net (ISO9249)	127 kW (170 hp) at 1,800 rpm
Piston Displacement	6.8L
Off-Level Capability	70% (35 deg.)
Maximum Flow	2 x 224 L/m (59 gpm)
Pilot	3.9 MPa (566 psi)
Pressure Boost	37.3 MPa (5,410 psi)
Operating Flow	30–224 L/m (7.9–59.2 gpm) 30–448 L/m (7.9–118.3 gpm) 31 L/m (8.2 gpm)
Operating Pressure 2-way electronically selectable	60–35 MPa (8,702–5,706 psi); 1-way Manually adjustable 21–25 MPa
System Operating Pressure	21.0 MPa (3,046 psi)
Standard	800-mm (32 in.) triple grouser (bolt-on pad ready)
Optional	700-mm (28 in.) triple grouser
Without Bucket	23 950 kg (52,800 lb.) 42.7 kPa (6.2 psi) 5400 kg (11,900 lb.)
ROPS Certification Weight	28 000 kg (61,730 lb.)
Of Heaviest Configuration	26 729 kg (58,930 lb.)
Of Lightest Configuration	23 802 kg (52,470 lb.)
Undercarriage With	800-mm (32 in.) 7930 kg (17,480 lb.)
Boom,	5.7-m (18 ft. 8 in.) With Arm 1950 kg (4,300 lb.)
Boom Cylinder Total Weight	395 kg (870 lb.)
Counterweight	5400 kg (11,900 lb.)
Batteries	24V (2 x 12 volt)
Engine Coolant (standard fill)	33.0 L (8.7 gal.)
Engine Oil (standard fill)	22.0 L (5.8 gal.)
Swing Mechanism (standard fill)	5.4 L (5.7 qt.)
Travel Final Device (each side, standard fill)	5.0 L (5.3 qt.)
Hydraulic System (standard fill)	280.0 L (74.0 gal.)
Hydraulic Tank (standard fill)	127.0 L (33.5 gal.)
B Maximum Depth Cut for	2.44-m (8 ft. 0 in.) 6460 mm (21 ft. 2 in.)
D Maximum Loading Height	6890 mm (22 ft. 7 in.)
E Minimum Slew Radius	3620 mm (11 ft. 10 in.)
F Maximum Vertical Wall Digging Depth	4880 mm (16 ft. 0 in.)
G Tail Swing Radius	2880 mm (9 ft. 5 in.)
B Overall Height With Boom Plumbing	3070 mm (10 ft. 0 in.)
C Overall Width (over tracks)	3180 mm (10 ft. 5 in.)
D Tail Length	2850 mm (9 ft. 4 in.)
D Tail Swing Radius	2880 mm (9 ft. 5 in.)
E Tumbler Distance	3650 mm (12 ft. 0 in.)
F Overall Length of Crawler	4440 mm (14 ft. 7 in.)
G Counterweight Clearance	1050 mm (3 ft. 5 in.)
H Overall Height (to top of cab)	3029 mm (9 ft. 11 in.)
I Ground Clearance	470 mm (19 in.)
J Overall Width of Upperstructure	2780 mm (9 ft. 1 in.)
K Track Gauge	2380 mm (7 ft. 10 in.)
L Shoe Width	800 mm (32 in.)
Cutting-Edge Bucket Tip Number	5.68-m (18 ft. 8 in.) Boom /
Width Volume Weight* Radius of Teeth	2.9-m (9 ft. 6 in.) Arm / Track Shoes
With Pin-On Bucket mm in. m cu. yd. kg lb. mm in.	700-mm (28 in.) Width 800-mm (32 in.) Width
2100 kg/m (3,500 lb./cu. yd.)	1700 kg/m (2,900 lb./cu. yd.) 1200 kg/m (2,000 lb./cu. yd.)
1800 kg/m (3,000 lb./cu. yd.)	1500 kg/m (2,500 lb./cu. yd.) 900 kg/m (1,500 lb./cu. yd.)
Manufacturer and Model John Deere PowerTech™ PVS	6.8L
