John Deere

655 P-Tier Crawler Loader

Name: 655 P-Tier Crawler Loader
Brand: John Deere
SKU: JOHNDEERE-98A0T

رقم القطعة: JOHNDEERE-98A0T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

655 P-Tier Crawler Loader

المواصفات

Displacement	6.8 L (414 cu. in.)
Engine Oil With Filter	24.6 L (6.5 gal.)
Model	655 P-Tier
Base Code	98A0T
Division	loaders
Product Family	crawler-loaders
SAE Net Rated Power	116 kW (155 hp) at 1,700 rpm
Net Peak Torque	689 Nm (508 ft.-lb.) at 1,400 rpm
System Relief Pressure	45 850 kPa (6,650 psi)
Forward and Reverse	10 km/h (6.2 mph)
Maximum (optional)	10 km/h (6.2 mph)
Maximum Flow at Unloaded High Idle	197 L/m (52 gpm)
Track Gauge	1740 mm (68.5 in.)
Grouser Width	510 mm (20 in.)
Track Length on Ground	2414 mm (95 in.)
Track Pitch	190 mm (7.5 in.)
Fuel Tank With Lockable Cap	263 L (69.5 gal.)
Cooling System With Recovery Tank	30.3 L (8.0 gal.)
Retrieval Hitch	62 kg (136 lb.)
Full-Length Rock Guards	180 kg (398 lb.)
Differential Pressure	1896 kPa (275 psi)
Diesel Exhaust Fluid (DEF) Reservoir	8.5 L (2.2 gal.)
Final-Drive Trash Guards	79 kg (155 lb.)
(8 ft.	1 in.) (27,432 lb.)
P Ripping Width	1740 mm (5 ft. 9 in.)
Retractable seat belt,	76 mm (3 in.) (conforms to SAE J386)
Pump Flow	189 L/m (50 gpm)
Hydraulic Reservoir and Filter	121.5 L (32.1 gal.)
General Purpose	2470 mm (97 in.) 1.9 m (2.4 cu. yd.) 1208 kg (2,665 lb.) 148 kN (33,271 lbf) 12 443 kg N/A
A Overall Height	3120 mm (10 ft. 3 in.)
reverse speed ratios of	100%, 115%, or 130% of forward ground speed; decelerator pedal controls ground speed to stop
Lift Cylinders	125 mm (4.9 in.) 70 mm (2.8 in.) 757 mm (29.8 in.)
Bucket-Dump Cylinder	160 mm (6.3 in.) 95 mm (3.7 in.) 493 mm (19.4 in.)
510-mm (20 in.) Grouser Width	24 622 cm (3,816 sq. in.)
560-mm (22 in.) Grouser Width	27 036 cm (4,191 sq. in.)
Multipurpose	2470 mm (97 in.) 1.6 m (2.1 cu. yd.) 1480 kg (3,262 lb.) 148 kN (33,271 lbf) 12 184 kg 8514 kg (18,731 lbf)
Transmission Reservoir With Filter	66.6 L (17.6 gal.)
Inner Final Drive (each)	8.0 L (2.1 gal.)
Outer Planetary (each)	15.6 L (4.1 gal.)
Base Weight	18 422 kg (40,614 lb.)
Lift-Cylinder Guards	18.4 kg (41 lb.)
Clam-Cylinder Protection for Multi-	50 kg (110 lb.)
560 mm (22 in.)	120 kg (265 lb.)
B Tread Depth With Double-Bar Grouser	35 mm (1.4 in.)
C Length to Front of Track	4920 mm (16 ft. 2 in.)
E Track Gauge	1740 mm (5 ft. 9 in.)
F Ground Clearance (excludes grouser	395 mm (15.6 in.)
G Dumping Height at	45 deg. 2665 mm (105 in.) G Dumping Height at 45 deg. (bucket) 2700 mm (106.3 in.)
H Reach at	45 deg. 1036 mm (41 in.) G Dumping Height at 45 deg. (blade) 3325 mm (130.9 in.)
I Maximum Digging Depth Below Grade	152 mm (6 in.) H Reach at 45 deg. (bucket) 930 mm (36.6 in.)
J Maximum Operating Height	4920 mm (193.7 in.) H Reach at 45 deg. (blade) 380 mm (15 in.)
K Maximum Height of Hinge Pin	3710 mm (146.1 in.) I Maximum Digging Depth Below Grade 205 mm (8.1 in.)
L Height of Hinge Pin, Transport	400 mm (15.7 in.) J Maximum Operating Height (open) 5700 mm (224.4 in.)
M Width of Bucket	2470 mm (97 in.) J Maximum Operating Height (closed) 4920 mm (193.7 in.)
N Width of Opening	1135 mm (44.7 in.)
Ripper Weight	845 kg (1,863 lb.)
O Ground Clearance Below Toolbar	215 mm (8.5 in.)
Q Toolbar Width	1941 mm (76.4 in.)
R Lifting Height	740 mm (29.1 in.)
S Ripping Depth	260 mm (10.2 in.)
T Additional Overall Length, Raised	665 mm (26.2 in.)
T Additional Overall Length, Lowered	685 mm (27 in.)
U Distance Between Teeth	870 mm (34.3 in.)
V Approach Angle, Ripper Raised	15 deg.
and a	79-kg (175 lb.) operator. For complete details, contact your John Deere dealer.
