AE50 - FB15U-12

Name: AE50 - FB15U-12
Brand: Komatsu
SKU: KOMATSU-AE50-FB15U-12

رقم القطعة: KOMATSU-AE50-FB15U-12

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

AE50 - FB15U-12

المواصفات

Tire type	Cushion/solid pneumatic
Power type	Electric (48 V battery)
Capacity (kg)	1 350 - 1 800
Capacity (lbs)	3,000 - 4,000
Drive motor control	AC Inverter
Relief Pressure - attachment (bar)	158.6
Hydraulic oil capacity (gal)	6.1
Hydraulic oil capacity (L)	23
Relief Pressure - attachment (psi)	2,300
Service weight (kg)	3 141
Service weight (lbs)	6,910
Axle loading - loaded front (lbs)	8,740
Axle loading - loaded front (kg)	3 973
Axle loading - loaded rear (kg)	532
Axle loading - loaded rear (lbs)	1,170
Axle loading - unloaded front (lbs)	3,510
Axle loading - unloaded front (kg)	1 595
Axle loading - unloaded rear (lbs)	3,400
Axle loading - unloaded rear (kg)	1 545
Travel speed, loaded/unloaded (mph)	10.0 / 11.0
Travel speed, loaded/unloaded (kph)	16.1 / 17.7
Lifting speed, loaded/unloaded (2 stage) (mm/s)	340 / 600
Lifting speed, loaded/unloaded (2 stage) (fpm)	66.9 / 118.1
Lowering speed, loaded/unloaded (2 stage) (fpm)	88.6 / 108.3
Lowering speed, loaded/unloaded (2 stage) (mm/s)	450 / 550
Maximum drawbar pull, loaded (lbs)	2,150
Maximum drawbar pull, loaded (kN)	9.6
Maximum gradeability (%)	19
Service brake, operation/control	Foot / Hydraulic
Parking brake, operation/control	Hand / Mechanical
Steering type	Fully Hydrostatic Power Steering
Drive motor (AC) (HP)	6.0 x 2
Drive motor (AC) (kW)	4.5 x 2
Pump motor (AC) (kW)	9
Pump motor (AC) (HP)	12.1
Battery voltage (V)	48
Battery capacity, maximum (Ah/6hr)	600
Minimum battery weight (kg)	723
Minimum battery weight (lbs)	1,590
Maximum battery weight (kg)	955
Maximum battery weight (lbs)	2,100
Power source type	Electric
Operation type	Sit-Down
Capacity @ 600 mm load center (kg)	1 350
Capacity @ 24 in load center (lbs)	3000
Load distance from center axle (2 stage)(in)	15.9
Load distance from center axle (2 stage)(mm)	405
Wheelbase (mm)	1 410
Wheelbase (in)	55.5
Height overhead guard (mm)	2 070
Height overhead guard (in)	81.5
Length to fork face (in)	81.1
Length to fork face (mm)	2 060
Overall width at drive tires (in)	43.7
Overall width at drive tires (mm)	1 110
Forks, thickness x width x length (mm)	35 x 100 x 1 070
Forks, thickness x width x length (in)	1.4 x 3.9 x 42.1
Carriage width/ITa class (in)	38.2 in / II
Carriage width/ITa class (mm)	970 mm / II
Ground clearance, center of wheelbase (mm)	125
Ground clearance, center of wheelbase (in)	4.9
Ground clearance under mast (mm)	95
Ground clearance under mast (in)	3.7
Right angle stacking aisle (mm)	3 160 / 3 358
Right angle stacking aisle (in)	124.4 / 132.2
Turning radius, outside (in)	68.9
Turning radius, outside (mm)	1 750
Free lift height (mm)	150
Free lift height (in)	5.9
Length, with standard forks (mm)	3 129
Length, with standard forks (in)	123.2
Mast height - extended (mm)	4 255
Mast height - extended (in)	167.5
Mast height - lowered (in)	84.4
Mast height - lowered (mm)	2 144
Maximum fork height (in)	129.9
Maximum fork height (mm)	3 300
Tilting angle, forward/backward (2 stage) (deg)	6 / 10
Tire type details	Cushion/solid pneumatic
Number of wheels, front/rear	2x / 2
Tire size - front	18 x 7-8
Tire size - rear	16 x 6-8
Tread - front (in)	37
Tread - front (mm)	940
Tread - rear (mm)	865
Tread - rear (in)	34.1
