WD600-6
رقم القطعة: KOMATSU-WD600-6
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
WD600-6
المواصفات
| Control valve | 3-spool type |
|---|---|
| Aspiration | Turbocharged, aftercooled, cooled EGR |
| Number of cylinders | 6 |
| Bore x stroke (in) | 5.1 x 20 |
| Bore x stroke (mm) | 130 x 510 |
| Piston displacement (L) | 23.15 |
| Governor | all-speed, electronic |
| SAEJ1995 - Gross (kW) | 396 |
| SAEJ1995 - Gross (HP) | 530 |
| ISO 9249 / SAE J1349 - Net (HP) | 527 * |
| Rated rpm | 1800 |
| Filter | Full-flow type |
| Method | Gear pump, force-lubrication |
| 1st forward (kph) | 6.7 |
| 1st forward (mph) | 4.2 |
| 1st reverse (mph) | 4.5 |
| 1st reverse (kph) | 7.3 |
| 2nd forward (kph) | 11.7 |
| 2nd forward (mph) | 7.3 |
| 2nd reverse (mph) | 8 |
| 2nd reverse (kph) | 12.8 |
| 3rd forward (mph) | 12.6 |
| 3rd forward (kph) | 20.3 |
| 3rd reverse (mph) | 13.7 |
| 3rd reverse (kph) | 22 |
| Fuel tank (US gal) | 189.7 |
| Fuel tank (L) | 718 |
| Relief valve setting (psi) | 3560 |
| Relief valve setting (MPa) | 24.5 |
| Blade lift | Raise, hold, lower, and float |
| Parking brake | Wet disc brake |
| Cooling Type | Water-cooled, 4-cycle |
| Fan drive method for radiator cooling | Hydraulic |
| ISO 9249 / SAE J1349 - Net (kW) | 393 * |
| Engine (L) | 86 |
| Engine (US gal) | 22.7 |
| Hydraulic system (US gal) | 117 |
| Hydraulic system (L) | 443 |
| Service brake | Hydraulically actuated, wet disc brakes actuate on four wheels |
| Piston displacement (in³) | 1413 |
| Air cleaner | Dry type with double elements and dust evacuator, plus dust indicator |
| Cooling system (L) | 147 |
| Steering angle | 43˚ each direction |
| Engine footnote | *Net horsepower at the maximum speed of radiator cooling fan is 374 kW 502 HP. EPA Tier 3 and EU Stage 3A emissions certified. |
| Fuel system | Direct injection |
| Steering system type | Articulated type, full-hydraulic power steering |
| Gross horsepower (HP) @ 1,800 rpm | 530 |
| Gross horsepower (kW) @ 1,800 rpm | 396 |
| Drive system | Four-wheel drive |
| Transmission footnote | Measured with 35/65-33 tires. ( ) : Look-up clutch ON. |
| 4th, forward (kph) | 33 |
| 4th, forward (mph) | 20.5 |
| 4th, reverse (kph) | 36 |
| 4th, reverse (mph) | 22.4 |
| Hydraulic pump | Piston pump |
| Capacity (at rated rpm) (US gpm) | 47.6 + 47.6 |
| Capacity (at rated rpm) (L/min) | 180 + 180 |
| Number of cylinders in hydraulic cylinders | 2 |
| Raise (s) | 2 |
| Minimum turning radius at the center of outside tire (ft , in) | 23 ft. 3 in |
| Minimum turning radius at the center of outside tire (mm) | 7075 |
| Final reduction gear | Planetary gear, single reduction |
| Differential gear | Conventional type |
| Reduction gear | Spiral bevel gear |
| 2nd, forward (lock-up clutch ON) (mph) | 7.7 |
| 2nd, forward (lock-up clutch ON) (kph) | 12.4 |
| 3rd, forward (lock-up clutch ON) (mph) | 13.5 |
| 3rd, forward (lock-up clutch ON) (kph) | 21.7 |
| 4th, forward (lock-up clutch ON) (kph) | 37.7 |
| 4th, forward (lock-up clutch ON) (mph) | 23.4 |
| Torque converter and transmission (US gal) | 21.9 |
| Torque converter and transmission (L) | 83 |
| Emergency brake | Parking brake is commonly used |
| Blade capacity (m³) | 8.0-10.6 |
| Blade capacity (yd³) | 10.5-13.8 |
| Net horsepower (HP) @ 1,800 rpm | 527 |
| Net horsepower (kW) @ 1,800 rpm | 393 |
| Front | Fixed, full-floating |
| Rear | Center-pin support, full-floating, 26˚ total oscillation |
| Cooling system (US gal) | 38.8 |
| Transmission type | Full-powershift, planetary type |
| Torque converter type | 3-element, single-stage, double-phase |
| Relief valve setting (kgf/cm²) | 250 |
| Hydraulic cylinders type for steering control | Double-acting, piston type |
| Tilt and pitch | Tilt-left, tilt-right, hold, pitch forward and back |
| Lower (s) | 1.3 |
| Tilt (left / right) (s) | 0.8 / 1.1 |
| Pitch (front / rear) (s) | 2.1 / 1.6 |
| Hydraulic cylinder type for implement control | Double-acting, piston type |
| Blade lift (number of cylinders- bore x stroke) (mm) | 1- 160 x 1080 |
| Blade lift (number of cylinders- bore x stroke) (in) | 1- 6.3 x 42.5 |
| Tilt and pitch (number of cylinders- bore x stroke) (mm) | 2- 180 x 237 |
| Tilt and pitch (number of cylinders- bore x stroke) (in) | 2- 7.0 x 9.3 |
| Axle (each front and rear) (US gal) | 41 |
| Axle (each front and rear) (L) | 155 |
