GR84B Rock Grapple Compact Equipment Attachment

John Deere

GR84B Rock Grapple Compact Equipment Attachment

رقم القطعة: JOHNDEERE-05R1T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

GR84B Rock Grapple Compact Equipment Attachment

المواصفات

ModelGR84B Rock Grapple
Base Code05R1T
Divisionconstruction-equipment
Product Familyconstruction-attachments
Weight570 kg (1,255 lb.)
Connection / Hydraulic12.7-mm (0.5 in.) quick-connect couplers
Connection / ElectricalNone
Connection / Vehicle Compatibility320G, 324G, 330 P-Tier, and 334 P-Tier SSLs; 325G, 331 P-Tier, 333
325G
P-Tier Large Frames
Compact Wheel Loaders
Width / Overall2135 mm (84 in.)
Width / Grapple Arm620 mm (24.4 in.)
Width / Grapples1660 mm (65.3 in.)
Length / Bucket Depth970 mm (38.2 in.)
Length / Grapple Closed1035 mm (40.7 in.)
Length / Grapple Opened1060 mm (41.7 in.)
Height / Grapple Closed830 mm (32.6 in.)
Height / Grapple Opened1170 mm (46 in.)
Grapple Opening / Tine Tip950 mm (37.4 in.)
Grapple Opening / Grapple Closed460 mm (18.1 in.)
Grapple Opening / Grapple Opened1035 mm (40.8 in.)
Grapple Opening / Pivot Pin Diameter35 mm (1.375 in.)
Hydraulics / Cylinder Bore Diameter64 mm (2.5 in.)
Hydraulics / Cylinder Rod Diameter36 mm (1.4 in.)
Hydraulics / Cylinder Stroke206 mm (8.1 in.)
Hydraulics / Maximum Operating Pressure24 000 kPa (3,500 psi)
