GS72B Scrap Grapple Compact Equipment Attachment

Name: GS72B Scrap Grapple Compact Equipment Attachment
Brand: John Deere
SKU: JOHNDEERE-05T1T

رقم القطعة: JOHNDEERE-05T1T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

GS72B Scrap Grapple Compact Equipment Attachment

Model	GS72B Scrap Grapple
Base Code	05T1T
Division	construction-equipment
Product Family	construction-attachments
Weight	505 kg (1,110 lb.)
325G	
P-Tier Small Frames	
316 P-Tier 317 P-Tier 318 P-Tier 320G	
Width / Overall	1830 mm (72 in.)
Width / Grapple Arm	620 mm (24.4 in.)
Width / Grapples	1540 mm (60.6 in.)
Length / Bucket Depth	840 mm (33 in.)
Length / Grapple Closed	1035 mm (40.7 in.)
Length / Grapple Opened	1060 mm (41.7 in.)
Height / Grapple Closed	830 mm (32.6 in.)
Height / Grapple Opened	1170 mm (46 in.)
Grapple Opening / Tine Tip	950 mm (37.4 in.)
Grapple Opening / Grapple Closed	460 mm (18.1 in.)
Grapple Opening / Grapple Opened	1035 mm (40.75 in.)
Grapple Opening / Pivot Pin Diameter	35 mm (1.375 in.)
Hydraulics / Cylinder Bore Diameter	64 mm (2.5 in.)
Hydraulics / Cylinder Rod Diameter	36 mm (1.4 in.)
Hydraulics / Cylinder Stroke	206 mm (8.1 in.)
Hydraulics / Maximum Operating Pressure	24 000 kPa (3,500 psi)
Hydraulics / Hydraulic Connection	12.7-mm (0.5 in.) quick- connect couplers
Hydraulics / Vehicle Compatibility	318 P-Tier, 324G, 330 P-Tier, and 334 P-Tier SSLs; 317
