John Deere

8R 490 Tractor

Name: 8R 490 Tractor
Brand: John Deere
SKU: JOHNDEERE-8410RW

رقم القطعة: JOHNDEERE-8410RW

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

8R 490 Tractor

المواصفات

Model	8R 490
Base Code	8410RW
Division	tractors
Product Family	row-crop-4wd-tractors
ENGINE / Displacement	827 cu in (13.6 L)
ENGINE / Engine Model	JD14
ENGINE / Rated speed	1,900 rpm
PTO torque rise	41%
FRONT AXLES / HYDRAULIC SYSTEM	Closed-center, pressure/flow compensated system with load sensing
INTEGRATED TECHNOLOGY / Integrated AutoTrac™	Standard
CAPACITIES / DEF tank	18.2 gal (69 L)
WHEELBASE / MFWD / ILS axle clearance	21.9 in (555 mm)
WEIGHT CAPACITIES / Max ballast level	52,910 lb (24,000 kg)
ENGINE / Aspiration	Single wastegated turbocharger air-to-air aftercooling and cooled exhaust gas recirculation
CAPACITIES / Fuel tank	247 gal (936 L)
ELECTRICAL SYSTEM / Alternator/Battery	Standard: 250 A / 12 V, Available: 330 A / 12 V
ELECTRICAL SYSTEM / Total cold cranking amps	3 X 950 CCA : 2,850 CCA Total
Rated PTO power (hp SAE) at rated engine speed 1	400 hp (298 kW)
Rated 1300 PTO power (hp SAE) at rated PTO speed	434 hp (324 kW)
Rated engine power PS (hp ISO) at rated engine speed (ECE-R120) 2	490 hp (360 kW)
Max engine power PS (hp ISO) at max engine power speed (ECE-R120) 2	539 hp (396 kW)
Intelligent Power Management (available), additional engine horsepower PS (hp ISO) at 1,900 rpm (rat	40 hp (29 kW)
Peak Power Intelligent Power Management (available), additional engine horsepower PS (hp ISO) at 1,7	40 hp (29 kW)
Max engine power PS (hp ISO) with boost at max engine power speed (ECE-R120) 2	579 hp (426 kW)
Engine peak torque (Nm) at max torque engine speed 2	2445 Nm
Engine power bulge 2	10%
ENGINE / Manufacturer	John Deere
FUEL SYSTEM / Required fuel type	Ultra low sulfur diesel (B30 diesel compatible)
TRANSMISSION / eAutoPowr™ EVT 40K	Available (Forward: 0.05 - 40 km/h, 40 km/h @ min erpm of 1200, with group 50 tires, 40 km/h @ min erpm of 1200, with group 49 tires Reverse: 0.05 - 30 km/h) 3
TRANSMISSION / eAutoPowr™ EVT 50K	Available (Forward: 0.05 - 50 km/h, 50 km/h @ min erpm of 1200, with group 50 tires, 50 km/h @ min erpm of 1260 , with group 49 tires Reverse: 0.05 - 30 km/h) 3
TRANSMISSION / eAutoPowr™ EVT 60K	Available (Forward: 0.05 - 60 km/h, 60 km/h @ min erpm of 1439, with group 50 tires, 60 km/h @ min erpm of 1510, with group 49 tires Reverse: 0.05 - 30 km/h) 3
ELECTRIC POWER GENERATION (Optional) / Power output	100 kW
ELECTRIC POWER GENERATION (Optional) / Voltage	480 VAC / 700 VDC
REAR AXLES / 140 x 2550 mm diameter (5.51 x 100.4 in), double flat axle with single taper hub	Available
REAR AXLES / 140 x 3010 mm diameter (5.51 x 118.5 in), double flat axle with single taper hub	Standard
FRONT AXLES / ILS - tread range 60 to 160 in (1524 to 4064 mm) 4.5 or 5 step drop	Standard w/ or w/o duals
FRONT AXLES / STEERING	Tilt & telescope steering with memory function, 345-mm steering wheel (all options)
FRONT AXLES / Reactive Command Steering (RCS) w/ electronic back-up pump	Standard: Variable ratio 15:1 to 20:1 (3.1-5.0 turns lock-to-lock) w/ tactile feedback, includes return-to-center capability
FRONT AXLES / Rear selective control valves with 1/2 in (12.7 mm) ISO couplers	Standard: 5; Available: 4 or 6
FRONT AXLES / Rear selective control valves with 3/4 in (19.05 mm) and 1/2 in (12.7 mm) ISO couplers	Available: 6 (SCV 1: 3/4 in coupler, SCV 2-6: 1/2 in couplers)
FRONT AXLES / Dual hydraulic pump	84 gpm (319.8 lpm)
FRONT AXLES / High flow dual hydraulic pump	110 gpm (418.2 lpm)
FRONT AXLES / Available flow at a single selective control valve - 1/2 in (12.7 mm) coupler	35 gpm (132 lpm)
FRONT AXLES / Available flow at a single selective control valve with High-Flow - 3/4 in (19.05 mm)	45 gpm (170 lpm)
FRONT AXLES / 3-POINT HITCH - REAR Lift capacity per OECD: 24 inch / 610 mm behind the coupler	\|
FRONT AXLES / Category 4N/3 w/ Quick-Coupler and sway blocks	Standard: 20,000 lb (9072 kg), Available: 24,000 lb (10,886 kg)
FRONT AXLES / Category 4N/3 w/ ball/hook ends and sway blocks	Standard: 19,841 lb (9000 kg)
FRONT AXLES / Category 4N/3 w/ ball/hook ends and deluxe sway stabilizers	Standard: 19,841 lb (9000 kg), Available: 24,000 lb (10,886 kg)
DRAWBAR / Category 5 with Category 4 insert	NA
DRAWBAR / Category 5 REAR POWER TAKE OFF (PTO)	19,000 lb (8636 kg) max vertical load
DRAWBAR / 1,000 rpm 20-spline 45 mm (1-3/4 in) PTO	Standard
DRAWBAR / 1,000 rpm / 1,000E rpm 20-spline 45 mm (1-3/4 in) and 1,300 rpm 22-spline 57.5mm (2-1/4 in	Available
3-POINT HITCH - FRONT / Lift capacity through full range 24 in (610 mm) in front of the coupler (Val	10,710 lb (4860 kg)
3-POINT HITCH - FRONT / FRONT POWER TAKE OFF (PTO)	Electrohydraulic switched via oil cooled multi-disc clutch
3-POINT HITCH - FRONT / 1,000 rpm 21-spline 35 mm (1-3/8 in) CCW rotation (facing PTO) type 2	Available
INTEGRATED TECHNOLOGY / Connectivity subscription	JDLink connectivity 4 can be enabled in John Deere Operations Center™
WHEELBASE / ILS	131.9 in (3350 mm)
AVERAGE BASE WEIGHT / EVT, ILS, VF650/65R38 front tires, VF750/75R46 rear tires, 85 gpm (321.76 lpm)	37,377 lb (16,954 kg)
AVERAGE BASE WEIGHT / EVT, ILS, Dual VF420/85R38 front tires, Dual VF480/95R50 rear tires, 950kg Int	43,193 lb (19,592 kg)
WEIGHT CAPACITIES / Max permissible weight pressure. erpm, are load dependent. 4 JDLink hardware com	52,910 lb (24,000 kg) - 40 kph, 52,910 lb (24,000 kg) - 50 kph w front brakes 44,100 lb (20,000 kg) - 50 kph w/o front brakes, 44,100 lb (20,000 kg) - 60 kph w front brakes
