John Deere

8RX 440 Tractor

Name: 8RX 440 Tractor
Brand: John Deere
SKU: JOHNDEERE-8500RW

رقم القطعة: JOHNDEERE-8500RW

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

8RX 440 Tractor

المواصفات

Model	8RX 440
Base Code	8500RW
Division	tractors
Product Family	row-crop-4wd-tractors
ENGINE / Displacement	827 cu in (13.6 L)
ENGINE / Engine Model	JD14
ENGINE / Rated speed	1,900 rpm
PTO torque rise	41%
INTEGRATED TECHNOLOGY / Integrated AutoTrac™	Standard
CAPACITIES / DEF tank	18.2 gal (69 L)
WEIGHT CAPACITIES / Max ballast level	50,706 lb (23,000 kg)
WEIGHT CAPACITIES / Max permissible weight	62,831 lb (28,500 kg)
ENGINE / Aspiration	Single wastegated turbocharger air-to-air aftercooling and cooled exhaust gas recirculation
CAPACITIES / Fuel tank	296.6 gal (1123 L)
DRAWBAR / REAR POWER TAKE OFF (PTO)	Independent, electrohydraulic switched via oil-cooled multi-disc clutch
ELECTRICAL SYSTEM / Alternator/Battery	Standard: 250 A / 12 V, Available: 330 A / 12 V
ELECTRICAL SYSTEM / Total cold cranking amps	3 X 950 CCA : 2,850 CCA Total
REAR AXLES / Drive type	Positive
REAR AXLES / Track width	21 in (533 mm), 24 in (610 mm), 30 in (762 mm)
REAR AXLES / HYDRAULIC SYSTEM	Closed-center, pressure/flow compensated system with load sensing
REAR AXLES / Tread spacing	Factory: 80 in (2032 mm), 88 in (2235.2 mm), 120 in (3048 mm) Aftermarket: 132 in (3352.8 mm), 136 in (3454.4), 144 in (3657.6 mm)
REAR AXLES / FRONT AXLE	1900 Series MFWD
WHEELBASE / MFWD	130.1 in (3305 mm)
Rated PTO power (hp SAE) at rated engine speed 1	355 hp (265 kW)
Rated 1300 PTO power (hp SAE) at rated PTO speed	386 hp (288 kW)
Rated engine power PS (hp ISO) at rated engine speed (ECE-R120) 2	440 hp (324 kW)
Max engine power PS (hp ISO) at max engine power speed (ECE-R120) 2	484 hp (356 kW)
Intelligent Power Management (available), additional engine horsepower PS (hp ISO) at 1,900 rpm (rat	40 hp (29 kW)
Peak Power Intelligent Power Management (available), additional engine horsepower PS (hp ISO) at 1,7	40 hp (29 kW)
Max engine power PS (hp ISO) with boost at max engine power speed (ECE-R120) 2	524 hp (385 kW)
Engine peak torque (Nm) at max torque engine speed 2	2196 Nm
Engine power bulge 2	10%
ENGINE / Manufacturer	John Deere
FUEL SYSTEM / Required fuel type	Ultra low sulfur diesel (B30 diesel compatible)
TRANSMISSION / eAutoPowr™ EVT 40K	Available (Variable forward: 0.05 - 40 km/h, 40 km/h @ min erpm of 1200 Varable reverse: 0.05 - 30 km/h)3
ELECTRIC POWER GENERATION (Optional) / Power output	100 kW
ELECTRIC POWER GENERATION (Optional) / Voltage	480 VAC / 700 VDC
DRAWBAR / Category 5 with Category 4 insert	\| 19,000 lb (8636 kg) max vertical load \|
DRAWBAR / 1,000 rpm 20-spline 45 mm (1-3/4 in) PTO	Standard
DRAWBAR / 1,000 rpm / 1,000E rpm 20-spline 45 mm (1-3/4 in) and 1,300 rpm 22-spline 57.5mm (2-1/4 in	Available
3-POINT HITCH - FRONT / Lift capacity through full range 24 in (610 mm) in front of the coupler (Val	10,710 lb (4860 kg)
INTEGRATED TECHNOLOGY / Connectivity subscription	JDLink connectivity 4 can be enabled in John Deere Operations Center™
REAR AXLES / STEERING	Tilt & telescope steering with memory function, 345-mm steering wheel (all options)
REAR AXLES / Reactive Command Steering (RCS) w/ electronic back-up pump	Standard: Variable ratio 15:1 to 20:1 (3.1-5.0 turns lock-to-lock) w/ tactile feedback, includes return-to-center capability
REAR AXLES / Rear selective control valves with 1/2 in (12.7 mm) ISO couplers	Standard: 5; Available: 4 or 6
REAR AXLES / Rear selective control valves with 3/4 in (19.05 mm) and 1/2 in (12.7 mm) ISO couplers	Available: 6 (SCV 1: 3/4 in coupler, SCV 2-6: 1/2 in couplers)
REAR AXLES / Dual hydraulic pump	84 gpm (319.8 lpm)
REAR AXLES / High flow dual hydraulic pump	110 gpm (418.2 lpm)
REAR AXLES / Available flow at a single selective control valve - 1/2 in (12.7 mm) coupler	35 gpm (132 lpm)
REAR AXLES / Available flow at a single selective control valve with High-Flow - 3/4 in (19.05 mm) c	45 gpm (170 lpm)
3-POINT HITCH - REAR / Category 4N/3 w/ Quick-Coupler sway blocks	Standard: 20,000 lb (9072 kg), Available: 24,000 lb (10,886 kg)
3-POINT HITCH - REAR / Category 4N/3 w/ ball/hook ends and sway blocks	Standard: 19,841 lb (9000 kg)
3-POINT HITCH - REAR / Category 4N/3 w/ ball/hook ends and deluxe sway stabilizers	Standard: 19,841 lb (9000 kg), Available: 24,000 lb (10,886 kg)
DRAWBAR / Category 5	19,000 lb (8636 kg) max vertical load
AVERAGE BASE WEIGHT / eVT, 21 in front, 21 in rear, 120 in spacing, 85 gpm dual pumps, 5 SCVs, PTO,	48,389 lb (21,949 kg)
ExactRate TM TRACTOR TANKS / Capacity	1,000 gal (3,785 L)
WEIGHT CAPACITIES / 1 PTO power for EVT models. Does not include optional equipment losses. Requires	4 JDLink hardware comes standard with the machine. You can turn on JDLink connected service in your John
WEIGHT CAPACITIES / 2 Equivalents: John Deere Standard RES10080, SAE Standards J1995.	Deere Operations Center account for free. JDLink requires a cellular connection to transfer information from
WEIGHT CAPACITIES / 3 Base tractor configuration on level ground. ERPMs are load dependent. 5 Shippi	machine to Operations Center. Consult your John Deere Dealer for coverage availability.
