Self-priming Pump, JALHASTI I (GOLD), 1.0 HP, Single Phase, 230 Volts, Size 25mm X 25mm
رقم القطعة: kirloskar-brothers-d11xa01009041033
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Overview Kirloskar Self-priming pumps comprise a Thermal Overload Protector for protection of the motor from overloading. Suitable for the voltage range 180 to 260 Volts (Single Phase Pump) and are thus perfectly suited for Water Supply to Overhead Tanks in Bungalows, Gardens/Fountains, Feed Water to RO Plants, Domestic Water Supply, Construction Sites, Home Pressure Boosting, Carashing, Lawn, Sprinklers. Key Features High Efficiency And Energy Saving Design - Innovative design manufactured at state of the art, plant ensures optimum efficiency and lower energy consumption resulting in significant cost savings Wide Voltage Designs - The Motor are designed to withstand wide voltage fluctuations from 150 to 240 Volts and reduces motor burning in case of low voltage Dynamically Balanced Rotating Parts - Minimum vibrations protect components from damage during operation, resulting in consistent performance as concentricity is maintained High-Grade F- Class Insulation - Robust design to withstand higher temperatures reducing the chances of motor burning and ensuring reliability, safety, and enhanced life Thermal Overload Protector(TOP) - The pump set features a TOP that protects the motor from overloading, shielding the motor and associated circuit from the effects of fault current Shielded Ball Bearing - The low-noise pumps are fitted with shielded ball bearing; So, no external lubrication require throughout the life cycle Easy Maintainable Designs - Easily maintainable design and better interchangeability of components ensures that the pump can be serviced even at remote locations by semi-skilled technicians High Suction Lift - The pump has a suction lift capacity of up to 7.5 meters with a high head, facilitating the pumping of water at high volumes for a variety of applications Enhanced Safety - All electrical parts of the pump are covered, which makes it safer to use
المواصفات
| Product Series | Jalhasti |
|---|---|
| Pump Model | JALHASTI I (GOLD) |
| Pump Type (Installation) | Surface |
| Pump Type (Application) | Self Priming |
| Power (In HP) | 01.00 |
| Phase | 1 |
| Rated Voltage (Volts) | 220 |
| Frequency (in Hz) | 50 |
| Speed (rpm) | 2700 |
| Head Minimum (in m) | 6 |
| Head Maximum (in m) | 50 |
| Discharge Minimum | 1000 |
| Discharge Maximum | 4280 |
| Discharge unit | LPH |
| Suction Size (in mm) | 25 |
| Delivery Size (in mm) | 25 |
| Impeller | BRASS |
| Delivery Casing | CAST IRON |
| Motor Body | ALUMINUM |
| Pump Shaft | CARBON STEEL |
| Sealing | Mechanical Seal |
| Certification/Accreditation | NON-ISI |
| Warranty | 24 Months |
| Gross Weight (kg) | 15.8 |
| Net Contents | 1 Pumpset, 1 Strainer |
| Item Code | D11XA01009041033 |
| Manufacturing location | Kaniyur, Tamil Nadu |
| No. of Stages | 1 |
| Max Solid Size (in mm) | clear cold water |
