Self-priming Pump, JALTARA (Gold), 0.5 HP, Single Phase, 220 Volts, Size 25mm X 25mm
رقم القطعة: kirloskar-brothers-d11xa00570401033
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Overview Kirloskar Self-priming pumps comprise a Thermal Overload Protector for protection of the motor from overloading. Suitable for the voltage range 180 to 260 Volts (Single Phase Pump) and are thus perfectly suited for Water supply to Overhead Tanks in Bungalows, Gardens/Fountains, Feed Water to RO Plants, Domestic Water Supply, Construction Sites, Home Pressure Boosting, Car washing, Lawn, Sprinklers. Key Features High Efficiency and Energy-Saving Design - Our innovative design, manufactured at a state-of-the-art plant, ensures optimum efficiency and lower energy consumption, resulting in significant cost savings. Wide Voltage Designs - The motors are designed to withstand wide voltage fluctuations, ranging from 180 to 260 Volts, reducing the risk of motor burning in case of low voltage. Dynamically Balanced Rotating Parts - Minimal vibrations protect components from damage during operation, ensuring consistent performance as concentricity is maintained. High-Grade F-Class Insulation - The robust design is engineered to withstand higher temperatures, reducing the chances of motor burning and ensuring reliability, safety, and an extended lifespan. Thermal Overload Protector (TOP) - The pump set features a TOP that protects the motor from overloading, shielding the motor and associated circuit from the effects of fault current. Shielded Ball Bearing - These low-noise pumps are fitted with shielded ball bearings, eliminating the need for external lubrication throughout the lifecycle. Easy Maintainable Designs - Easily maintainable design and better interchangeability of components ensures that the pump can be serviced even at remote locations by semi-skilled technicians High Suction Lift - The pump boasts a suction lift capacity of up to 7.5 meters with a high head, facilitating the pumping of water at high volumes for a variety of applications. Enhanced Safety - All electrical parts of the pump are covered, making it safer to use.
المواصفات
| Product Series | Jaltara |
|---|---|
| Pump Model | JALTARA (Gold) |
| Pump Type (Installation) | Surface |
| Pump Type (Application) | Self Priming |
| Power (In HP) | 00.50 |
| Phase | 1 |
| Rated Voltage (Volts) | 220 |
| Frequency (in Hz) | 50 |
| Speed (rpm) | 2650 |
| Head Minimum (in m) | 6 |
| Head Maximum (in m) | 36 |
| Discharge Minimum | 850 |
| Discharge Maximum | 3000 |
| Discharge unit | lph |
| Suction Size (in mm) | 25 |
| Delivery Size (in mm) | 25 |
| Impeller | Brass |
| Delivery Casing | Cast Iron |
| Motor Body | Aluminium |
| Pump Shaft | Carbon Steel |
| Warranty | 24 Months |
| Gross Weight (kg) | 10 |
| Net Contents | 1 Pumpset, 1 Strainer |
| Item Code | D11XA00570401033 |
| Manufacturing location | Kaniyur, Tamil Nadu |
| No. of Stages | 1 |
