Self-priming Pump, JALRAAJ ULTRA, 0.5 HP, Single Phase, 220 Volts, Size 25mm X 25mm

Kirloskar Brothers

Self-priming Pump, JALRAAJ ULTRA, 0.5 HP, Single Phase, 220 Volts, Size 25mm X 25mm

رقم القطعة: kirloskar-brothers-d11xa00540401033

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Overview Kirloskar Jalraaj Ultra 0.5 Hp Self-priming pumps feature a Thermal Overload Protector for motor protection from overloading. Suitable for 180 to 260 Volts (Single Phase). For Water supply to overhead tanks in bungalows, Gardens/ fountains, Feed water to RO plants, Domestic water supply, Construction site, Home pressure boosting, Car washing, and Lawn sprinklers. Key Features Shielded Ball Bearings - The low-noise pumps are fitted with shielded ball bearings; so, no external lubrication is required throughout the life cycle High Efficiency and Energy Saving Design - Innovative design manufactured at a state of art, plant ensures optimum efficiency and lower energy consumption resulting in significant cost savings Dynamically Balanced Rotating Parts - Minimum vibrations protect components from damage during operation, resulting in consistent performance as concentration is maintained Easy Maintainable Design - Easily maintainable design and better interchangeability of components so that the pump can be serviced even at remote locations by semi-skilled technicians TOP (Thermal Overload Protector) - The pump set features a Thermal Overload Protector that protects the motor from overloading, shielding the motor and associated circuit from fault current Lightweight and Compact Design - It allows users to carry the pump anywhere easily, adding to its portability and convenience of use High Suction Lift - The pump has a suction lift capacity of up to 7.5 meters with a high head, facilitating the pumping of water at high volumes for a variety of applications High-Quality Aluminum Motor Body - Special grade aluminum motor body provides high resistance to corrosion, better heat dissipation, and lowers the pump's overall weight for enhanced portability Enhanced Safety Features - All electrical parts of the pump are covered, which makes it safer to use Wide Voltage Design - The motor is designed to withstand wide voltage fluctuations ranging from 180 to 260 Volts, thus reducing the possibility of motor burning in case of low voltage

المواصفات

Product SeriesJalraaj Ultra
Pump ModelJALRAAJ ULTRA
Pump Type (Installation)Surface
Pump Type (Application)Self Priming
Power (In HP)00.50
Phase1
Rated Voltage (Volts)220
Frequency (in Hz)50
Speed (rpm)2700
Head Minimum (in m)6
Head Maximum (in m)26
Discharge Minimum430
Discharge Maximum1800
Discharge unitLPH
Suction Size (in mm)25
Delivery Size (in mm)25
ImpellerBrass
Delivery CasingCast Iron
Motor BodyAluminium
Pump ShaftCarbon Steel
SealingMechanical Seal
Warranty18 Months
Gross Weight (kg)8
Net Contents1 Pumpset, 1 Strainer
Item CodeD11XA00540401033
Country of ManufactureIndia
Manufacturing locationKaniyur, Tamil Nadu
No. of Stages1
