Vacuum Pump, DV-40 CS, 5 HP, Three Phase, 415 Volts, Size 40mm X 40mm
رقم القطعة: kirloskar-brothers-d14140505114
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Overview Kirloskar vacuum pump is majorly used for priming of large pumps. KIrloskar 5 hp pump(Three Phase Pump) as the name suggests, are also used to create a vacuum by enabling evacuation of air and thus is widely used for applications like Priming of large Pumps, evacuation of air from suction pipes and chambers, twist drilling machine, removing water from pulp layer, labeling, bottle filling, de-odorizing, drying, evaporation, distillation, filtration, sterilization, condensation, degasification, sucking gases, extrusion machines. Wide Voltage Motor Designs - The Motor are designed to withstand wide voltage fluctuations from 180 to 455 Volts and reduces motor burning in case of low voltage Designed to Prevent Overloading - Lesser chances of motor burning as it does not get overloaded even if the pump is operated at a head lower than recommended, thus ensuring substantial cost savings due to low maintenance and breakdown Replaceable Wearing Parts - All wearing parts within the pumps are easily accessible and replaceable which facilitates ease of maintenance thereby extending the life of the pump Dynamically Balanced Rotating Parts - Minimum vibrations protect components from damage during operation, resulting in consistent performance as concentricity is maintained
المواصفات
| Product Series | DV |
|---|---|
| Pump Model | DV-40 CS |
| Pump Type (Installation) | Surface |
| Pump Type (Application) | Vacuum Pump |
| Power (In HP) | 05.00 |
| Phase | 3 |
| Rated Voltage (Volts) | 415 |
| Frequency (in Hz) | 50 |
| Speed (rpm) | 1450 |
| Suction Size (in mm) | 40 |
| Delivery Size (in mm) | 40 |
| Impeller | Stainless Steel |
| Delivery Casing | Cast Iron |
| Motor Body | Cast Iron |
| Pump Shaft | Carbon Steel |
| Sealing | Gland packed |
| Warranty | 12 Months |
| Gross Weight (kg) | 260 |
| Net Contents | 1 Pumpset |
| Item Code | D14140505114 |
| Manufacturing location | Dewas, Madhya Pradesh |
| No. of Stages | 1 |
| Air flow maximum | 73.8 |
| Air flow unit | m3/hr |
| Vacuum maximum | 635 |
| Vacuum unit | mmHg |
