Vacuum Pump, KV-30, 3 HP, Three Phase, 415 Volts, Size 32mm X 32mm

Vacuum Pump, KV-30, 3 HP, Three Phase, 415 Volts, Size 32mm X 32mm

Name: Vacuum Pump, KV-30, 3 HP, Three Phase, 415 Volts, Size 32mm X 32mm
Brand: Kirloskar Brothers
SKU: kirloskar-brothers-d12080300223

رقم القطعة: kirloskar-brothers-d12080300223

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Overview Kirloskar Vacuum Pump 3 hp (Three Phase Pump) is majorly used for priming large pumps. As the name suggests, these are also used to create a ‘vacuum’ by enabling evacuation of air and thus are widely used for applications like Priming of Large Pump, Evacuation of Air from Suction Pipes and Chambers, Twist Drilling Machines, Removing Water from Pulp Layer, Labeling, Bottle Filling, De-odorizing, Drying, Evaporation, Distillation, Filtration, Sterilization, Condensation, Degasification, Sucking Gases, Extrusion Machines. Key Features Wide Voltage Motor Designs - The Motor are designed to withstand wide voltage fluctuations from 300 to 440 Volts and reduces motor burning in case of low voltage Designed to Prevent Overloading - Lesser chances of motor burning as it does not get overloaded even if the pump is operated at a head lower than recommended, thus ensuring substantial cost savings due to low maintenance and breakdown Replaceable Wearing Parts - All wearing parts within the pumps are easily accessible and replaceable which facilitates ease of maintenance thereby extending the life of the pump Dynamically Balanced Rotating Parts - Minimum vibrations protect components from damage during operation, resulting in consistent performance as concentricity is maintained

المواصفات

Product Series	KV
Pump Model	KV-30
Pump Type (Installation)	Surface
Pump Type (Application)	Vacuum Pump
Power (In HP)	03.00
Phase	3
Rated Voltage (Volts)	415
Frequency (in Hz)	50
Speed (rpm)	2840
Suction Size (in mm)	32
Delivery Size (in mm)	32
Impeller	Stainless Steel
Delivery Casing	Cast Iron
Motor Body	Cast Iron
Pump Shaft	Carbon Steel
Sealing	Mechanical Seal
Warranty	12 Months
Gross Weight (kg)	57
Net Contents	1 Pumpset
Item Code	D12080300223
Manufacturing location	Dewas, Madhya Pradesh
No. of Stages	1
Air flow maximum	55
Air flow unit	m3/hr
Vacuum maximum	650
Vacuum unit	mmHg
