Multiflo® APNH Polyethylene Pontoon Barge System

Weir

Multiflo® APNH Polyethylene Pontoon Barge System

Name: Multiflo® APNH Polyethylene Pontoon Barge System
Brand: Weir

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Multiflo® APNH polyethylene pontoon barges are a floating, steel-frame barge systems designed with the capability to mount up to 20 floats to suit the required buoyant capacity. Frequently used as a pump barge, they provide great flexibility, with mounting options to suit a variety of pumps including horizontal, vertical and submersible pumps. Due to their lighter construction compared to steel barges, they are also easier to move around site. Each float is made from UV-resistant, corrosion-free, low-density polyethylene (PE) and is roto-moulded for seamless construction. When combined with our range of Multiflo® dewatering pumps , these barge systems provide an efficient and reliable dewatering solution across a number of different industries. Particularly in open pit mining, surface extraction and tailings water reclaim applications. Compared to other types of pump barges, Multiflo® APNH polyethylene pontoon barges offer the following benefits: Superior durability and strength Fully scalable design allowing the option to add more pontoons in the future System is flexible with mounting options to suit a variety of pumps Available in a variety of configurations from four to twenty floats Come standard with a galvanised carbon steel platform structure, fibreglass reinforced deck grating and painted or galvanised handrails Enhanced safety features including a flotation life ring and a pump baseplate with pump lifting equipment for safer servicing Marine naval engineering analysis to ensure great stability and buoyancy For more information about our range of Multiflo® barges and pontoons, please get in touch with our team.

المواصفات

Brand line	Multiflo®
Product type	Barges and Pontoons
DESIGN	Modular pontoon - comprising multiple independent flotation pontoons instead of a single hull.
MAIN MATERIAL OF CONSTRUCTION	Polyethylene (PE)
NUMBER OF PONTOONS	From 4 to 18 pontoons
OVERALL DIMENSIONS	From 3.1m x 3.0m x 3.7m to 10.0m x 4.3m x 3.7m
DECK DIMENSIONS	From 3.1m x 3.0m x 3.7m to 10.0m x 4.3m x 3.7m
PONTOON WEIGHT WITHOUT PUMP AND EQUIPMENT	From 1500kg to 6500kg
MAXIMUM PUMP AND EQUIPMENT WEIGHT	From 1000kg to 6500kg
MAXIMUM COMBINED PUMP AND PONTOON WEIGHT	From 2500kg to 13000kg
AMBIENT TEMPERATURE OPERATING RANGE	From -45°C to +40°C
SUBMERGANCE RANGE	From 65% to 70%
Catalogue category	Barges and Pontoons
