330 GC Excavator | 30 Ton Excavator / Digger

Caterpillar

330 GC Excavator | 30 Ton Excavator / Digger

Name: 330 GC Excavator | 30 Ton Excavator / Digger
Brand: Caterpillar
SKU: CAT-126533

رقم القطعة: CAT-126533

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

330 GC Excavator | 30 Ton Excavator / Digger

المواصفات

Engine Model	Cat® C7.1
Bore	105 mm
Stroke	135 mm
Displacement	7.01 l
Note (1)	Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.
Note (2)	¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use. Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. **Engines with no aftertreatment devices are compatible with higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).
Air Conditioning	The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. If equipped with R134a (Global Warming Potential = 1430), the system contains 0.85 kg (1.9 lb) of refrigerant which has a CO2 equivalent of 1.216 metric tonnes (1.340 tons). If equipped with R1234yf (Global Warming Potential = 0.5), the system contains 0.78 kg (1.7 lb) of refrigerant which has a CO2 equivalent of 0.001 metric tonnes (0.001 tons).
Note	Long undercarriage, Reach boom, R3.2 m (10'6") stick, Heavy Duty (HD) 1.54 m³ (2.01 yd³) bucket, 800 mm (31") triple grouser shoes and 6700 kg (14,770 lb) counterweight.
Cooling System	25 l
DEF Tank	41 l
Final Drive - Each	5.5 l
Model	330 GC
Product Page	https://www.cat.com/en_US/products/new/equipment/excavators/medium-excavators/126533.html
Caterpillar Category	Medium Excavators
Caterpillar Category Path	Products > Equipment > Excavators > Medium Excavators > 330 GC
Caterpillar Product Family	equipment
Caterpillar Product Page ID	126533
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20241204-7cf33-d228e
Transport Width	3190 mm
Fuel Tank Capacity	474 l
Emissions	Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, and Japan 2014 emission standards.
Operating Weight	30900 kg
Recyclability	97%
Hydraulic Tank	147 l
Engine Oil	25 l
Ground Clearance	490 mm
Tail Swing Radius	3130 mm
Net Power - ISO 9249	150 kW
Maximum Reach at Ground Level	10690 mm
Net Power - ISO 9249 (DIN)	204 hp (metric)
Engine Power - ISO 14396	151 kW
Engine Power - ISO 14396 (DIN)	205 hp (metric)
Biodiesel Capability	Up to B20¹
Maximum Digging Depth	7260 mm
Boom	Reach 6.15 m (20'2")
Stick	Reach 3.2 m (10'6")
Bucket	HD 1.54 m³ (2.01 yd³)
Maximum Cutting Height	10020 mm
Maximum Loading Height	6930 mm
Minimum Loading Height	2280 mm
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom	7100 mm
Maximum Vertical Wall Digging Depth	6030 mm
Bucket Digging Force - ISO	179 kN
Stick Digging Force - ISO	126 kN
Main System - Maximum Flow	560 L/min (148 gal/min)
Maximum Pressure - Equipment	35000 kPa
Maximum Pressure - Travel	35000 kPa
Maximum Pressure - Swing	28400 kPa
Swing Speed	11.5 r/min
Maximum Swing Torque	105 kN·m
Swing Mechanism — Note (1)	*For CE-marked machine default value may be set lower.
Hydraulic System - Including Tank	310 l
Shipping Height - Top of Cab	3050 mm
Handrail Height	3050 mm
Shipping Length	10420 mm
Counterweight Clearance	1110 mm
Track Length	4860 mm
Length to Center of Rollers	3990 mm
Track Gauge	2590 mm
Swing Drive - Each	10 l
