Caterpillar

326 Hydraulic Excavator

Name: 326 Hydraulic Excavator
Brand: Caterpillar
SKU: CAT-126537

رقم القطعة: CAT-126537

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

326 Hydraulic Excavator

المواصفات

Engine Model	Cat® C7.1
Bore	105 mm
Stroke	135 mm
Displacement	7.01 l
Note (1)	Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.
Note (2)	¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use. Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. **Engines with no aftertreatment devices are compatible with higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).
Air Conditioning	The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. If equipped with R134a (Global Warming Potential = 1430), the system contains 0.8 kg (1.8 lb) of refrigerant which has a CO2 equivalent of 1.144 metric tonnes (1.261 tons). If equipped with R1234yf (Global Warming Potential = 0.5), the system contains 0.75 kg (1.7 lb) of refrigerant which has a CO2 equivalent of 0.001 metric tonnes (0.001 tons).
Note	Long undercarriage, Reach boom, R2.95 m (9'8") stick, 1.54 m³ (2.01 yd³) Heavy Duty (HD) bucket, 600 mm (24") triple grouser shoes and 4600 kg (10,140 lb) counterweight.
Cooling System	25 l
DEF Tank	41 l
Final Drive - Each	4.5 l
Model	326
Product Page	https://www.cat.com/en_US/products/new/equipment/excavators/medium-excavators/126537.html
Caterpillar Category	Medium Excavators
Caterpillar Category Path	Products > Equipment > Excavators > Medium Excavators > 326
Caterpillar Product Family	equipment
Caterpillar Product Page ID	126537
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20241204-a2bcd-4a963
Transport Width	3190 mm
Fuel Tank Capacity	474 l
Emissions	Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards.
Operating Weight	25600 kg
Recyclability	97%
Hydraulic Tank	147 l
Engine Oil	25 l
Ground Clearance	1060 mm
Tail Swing Radius	3000 mm
Net Power - ISO 9249	149.8 kW
Maximum Reach at Ground Level	10120 mm
Net Power - ISO 9249 (DIN)	204 hp (metric)
Engine Power - ISO 14396	151 kW
Engine Power - ISO 14396 (DIN)	205 hp (metric)
Biodiesel Capability	Up to B20¹
Maximum Digging Depth	6820 mm
Boom	Reach 5.9 m (19'4")
Stick	Reach 2.95 m (9'8")
Bucket	HD 1.54 m³ (2.01 yd³)
Maximum Cutting Height	9680 mm
Maximum Loading Height	6610 mm
Minimum Loading Height	2390 mm
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom	6650 mm
Maximum Vertical Wall Digging Depth	5340 mm
Bucket Digging Force - ISO	166 kN
Stick Digging Force - ISO	121 kN
Main System - Maximum Flow	481 l/min (127 gal/min)
Maximum Pressure - Equipment	35000 kPa
Maximum Pressure - Travel	35000 kPa
Maximum Pressure - Swing	28400 kPa
Swing Speed	9.9 r/min
Maximum Swing Torque	106 kN·m
Swing Mechanism — Note (1)	*For CE-marked machine default value may be set lower.
Hydraulic System - Including Tank	310 l
Shipping Height - Top of Cab	3000 mm
Handrail Height	3000 mm
Shipping Length	10060 mm
Counterweight Clearance	1060 mm
Track Length	4640 mm
Length to Center of Rollers	3830 mm
Track Gauge	2590 mm
Maximum Pressure - Equipment - Lift Mode	38000 kPa
Swing Drive	11.5 l
