D5 Dozer
رقم القطعة: CAT-15969993
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
D5 Dozer
المواصفات
| Engine Model | Cat C7.1 |
|---|---|
| Note (1) | Rated horsepower at 1770 rpm. Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator. Advertised power is tested per the specified standard in effect at the time of manufacture. |
| Note (2) | Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) ** or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. ** Engines with no aftertreatment devices can use higher blends, up to 30% biodiesel. |
| Note (3) | Basic machine specs provided below. For complete specifications and dimensions by configuration, blade and track shoe offerings and more, please visit the product download section to view the full Technical Specifications document. |
| Note (4) | Machine Build Number 17B |
| Air Conditioning | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. - If equipped with R134a (Global Warming Potential = 1430), the system contains 1.36 kg (3 lb) of refrigerant which has a CO2 equivalent of 1.95 metric tonnes (2.14 tons). |
| Fuel Tank | 315 l |
| DEF Tank | 16 l |
| Model | D5 |
| Product Page | https://www.cat.com/en_US/products/new/equipment/dozers/medium-dozers/15969993.html |
| Caterpillar Category | Medium Dozers |
| Caterpillar Category Path | Products > Equipment > Dozers > Medium Dozers > D5 |
| Caterpillar Product Family | equipment |
| Caterpillar Product Page ID | 15969993 |
| Datasheet URL | https://s7d2.scene7.com/is/content/Caterpillar/CM20190522-e0145-40b82 |
| Emissions | U.S. EPA Tier 4 Final/EU Stage V/Japan 2014 (Tier 4 Final)/Korea Stage V |
| Operating Weight | 19170 kg |
| Recyclability | 97% |
| Ground Pressure | 47.6 kPa |
| Width of Standard Shoe | 610 mm |
| Power - Net | 127 kW |
| Powertrain | Fully Automatic 3-Speed |
| Net Power - Rated - ISO 9249/SAE J1349 | 127 kW |
| Blade | VPAT |
| Net Power (Rated) - ISO 9249 (DIN) | 172 mhp |
| Blade Capacity | 3.5 m³ |
| VPAT — Operating Weight | 17180 kg |
| LGP VPAT — Ground Pressure | 32.6 kPa |
| LGP VPAT — Width of Standard Shoe | 840 mm |
| LGP VPAT — Blade | LGP VPAT |
| LGP VPAT — Blade Capacity | 4 m³ |
| Fine Grading VPAT — Operating Weight | 17780 kg |
| Fine Grading VPAT — Ground Pressure | 41.4 kPa |
| Push Arm — Operating Weight | 17340 kg |
| Push Arm — Ground Pressure | 48.2 kPa |
| Push Arm — Blade | Semi-Universal (SU) |
| Push Arm — Blade Capacity | 4.3 m³ |
| Note (1) (2) | Configurations and features may vary by region. Please consult your Cat dealer for availability in your area. |
