C144-2
رقم القطعة: KOMATSU-C144-2
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
C144-2
المواصفات
| Weight (kg) | 1,407 |
|---|---|
| Weight (lbs) | 3,102 |
| Max width (in) | 71.8 |
| Max width (mm) | 1,823 |
| Height including rotator (mm) | 1,810 |
| Height including rotator (in) | 71.2 |
| Feed speed (m/s) | 0-5/6.5 |
| Feed speed (ft/s) | 0-16.4/21.3 |
| Gross feed force (kN) | 29.6/23.8 |
| Gross feed force (lbf) | 6,654/5,350 |
| Delimbing knives, number | 5 |
| Saw motor (in^3/rev) | 1.16 |
| Saw motor (cm^3/rev) | 19 |
| Max hydraulic flow (L/min) | 320/330 |
| Max hydraulic flow (gpm) | 84.5/87.2 |
| Max hydraulic pressure (psi) | 4,061 |
| Max hydraulic pressure (MPa) | 28 |
| Cutting diameter, max (in) | 29.5 |
| Cutting diameter, max (mm) | 750 |
| Head opening, max (in) | 25.6 |
| Head opening, max (mm) | 650 |
| Feed roller type | Steel |
| Height to top knife (in) | 62.1 |
| Height to top knife (mm) | 1,579 |
| Feed roller opening, max (in) | 29.5 |
| Feed roller opening, max (mm) | 750 |
| Opening front knives (mm) | 650 |
| Opening front knives (in) | 25.6 |
| Opening rear knives (mm) | 800 |
| Opening rear knives (in) | 31.5 |
| Delimbing diameter, tip to tip (in) | 20.9 |
| Delimbing diameter, tip to tip (mm) | 530 |
| Bar (in) | 32.5/35.4 |
| Bar (cm) | 82.5/90 |
