C164-0
رقم القطعة: KOMATSU-C164-0
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
C164-0
المواصفات
| Weight (kg) | 1,672.5 |
|---|---|
| Weight (lbs) | 3,687 |
| Max width (in) | 75 |
| Max width (mm) | 1,905 |
| Height including rotator (mm) | 1,848 |
| Height including rotator (in) | 72.8 |
| Feed speed (m/s) | 0-5 |
| Feed speed (ft/s) | 0-16.4 |
| Gross feed force (kN) | 35.4/29.6 |
| Gross feed force (lbf) | 7,957/6,654 |
| Delimbing knives, number | 5 |
| Saw motor (in^3/rev) | 1.16 |
| Saw motor (cm^3/rev) | 19 |
| Max hydraulic flow (L/min) | 380/320 |
| Max hydraulic flow (gpm) | 100.4/84.5 |
| Max hydraulic pressure (psi) | 4,061 |
| Max hydraulic pressure (MPa) | 28 |
| Cutting diameter, max (in) | 32.7 |
| Cutting diameter, max (mm) | 830 |
| Head opening, max (in) | 29.5 |
| Head opening, max (mm) | 750 |
| Feed roller type | Finger feed rollers |
| Height to top knife (in) | 66.5 |
| Height to top knife (mm) | 1,690 |
| Feed roller opening, max (in) | 33.5 |
| Feed roller opening, max (mm) | 850 |
| Opening front knives (mm) | 750 |
| Opening front knives (in) | 29.5 |
| Opening rear knives (mm) | 950 |
| Opening rear knives (in) | 37.4 |
| Delimbing diameter, tip to tip (in) | 24.4 |
| Max recommended tree size (in) | 25.2 |
| Delimbing diameter, tip to tip (mm) | 620 |
| Max recommended tree size (mm) | 640 |
| Bar (in) | 35.4/38.2 |
| Max possible tree size (mm) | 750 |
| Bar (cm) | 90/97 |
| Max possible tree size (in) | 29.5 |
