S172-1
رقم القطعة: KOMATSU-S172-1
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
S172-1
المواصفات
| Weight (kg) | 1,739 |
|---|---|
| Weight (lbs) | 3,833 |
| Max width (in) | 76.3 |
| Max width (mm) | 1,937 |
| Height including rotator (mm) | 2,222 |
| Height including rotator (in) | 87.5 |
| Feed speed (m/s) | 0-5 |
| Feed speed (ft/s) | 0-16.4 |
| Gross feed force (kN) | 40.2 |
| Gross feed force (lbf) | 9,037 |
| Delimbing knives, number | 4 |
| Saw motor (in^3/rev) | 1.16 |
| Saw motor (cm^3/rev) | 19 |
| Max hydraulic flow (L/min) | 300 |
| Max hydraulic flow (gpm) | 79.3 |
| Max hydraulic pressure (psi) | 4,061 |
| Max hydraulic pressure (MPa) | 28 |
| Cutting diameter, max (in) | 29.5 |
| Cutting diameter, max (mm) | 750 |
| Head opening, max (in) | 28.1 |
| Head opening, max (mm) | 713 |
| Feed roller type | Steel |
| Height to top knife (in) | 69.9 |
| Height to top knife (mm) | 1,776 |
| Feed roller opening, max (in) | 28.1 |
| Feed roller opening, max (mm) | 713 |
| Opening front knives (mm) | 757 |
| Opening front knives (in) | 29.8 |
| Opening front knife to rear knife (in) | 30.4 |
| Opening front knife to rear knife (mm) | 772 |
| Delimbing diameter, tip to tip (in) | 19.7 |
| Delimbing diameter, tip to tip (mm) | 500 |
| Bar (in) | 35.4 |
| Bar (cm) | 90 |
| Weight (lbs) (Weight) | Dry weight, incl rotator, from 3,833 |
| Weight (kg) (Weight) | Dry weight, incl rotator, from 1,739 |
