370E-0
رقم القطعة: KOMATSU-370E-0
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
370E-0
المواصفات
| Weight (kg) | 1,600 |
|---|---|
| Weight (lbs) | 3,530 |
| Height including rotator (mm) | 2,080 |
| Height including rotator (in) | 81.9 |
| Feed speed (m/s) | 0-5 |
| Feed speed (ft/s) | 0-16.4 |
| Gross feed force (kN) | Feed roller motor dependent. Debarking: 21 kN / 25.7 kN. Non debarking: 28.3 kN / 30.8 kN |
| Gross feed force (lbf) | Feed roller motor dependent. Debarking: 4,720/5,778. Non debarking: 6,362/6,924 |
| Delimbing knives, number | 6 |
| Saw motor (in^3/rev) | 1.16 |
| Saw motor (cm^3/rev) | 19 |
| Max hydraulic flow (L/min) | Feed roller motor dependent. Debarking: 225 L/min / 275 L/min. Non debarking: 300 L/min / 330 L/min |
| Max hydraulic flow (gpm) | Feed roller motor dependent. Debarking: 59.4 gpm / 72.7 gpm. Non debarking: 79.3 gpm / 87.2 gpm |
| Max hydraulic pressure (psi) | 4,061 |
| Max hydraulic pressure (MPa) | 28 |
| Cutting diameter, max (in) | 27.6 |
| Cutting diameter, max (mm) | 700 |
| Feed roller type | Steel or rubber rollers with anti-slip protection |
| Height to top knife (in) | 70 |
| Height to top knife (mm) | 1,780 |
| Feed roller opening, max (in) | 23.6 |
| Feed roller opening, max (mm) | 600 |
| Opening front knives (mm) | 640 |
| Opening front knives (in) | 25.2 |
| Opening rear knives (mm) | 750 |
| Opening rear knives (in) | 29.5 |
| Delimbing diameter, tip to tip (in) | 19.7 |
| Delimbing diameter, tip to tip (mm) | 500 |
| Bar (in) | 32.5 |
| Bar (cm) | 82.5 |
| Recommended working range (in) | 3.9-11 |
| Recommended working range (mm) | 100-280 |
