C93-1
رقم القطعة: KOMATSU-C93-1
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
C93-1
المواصفات
| Weight (kg) | 1,020 |
|---|---|
| Weight (lbs) | 2,205 |
| Max width (in) | 55.5 |
| Max width (mm) | 1,410 |
| Height including rotator (mm) | 1,530 |
| Height including rotator (in) | 60.2 |
| Feed speed (m/s) | 0-5/0-6 |
| Feed speed (ft/s) | 0-16.4/0-19.7 |
| Gross feed force (kN) | 28.4 / 23.8 |
| Gross feed force (lbf) | 6,385 / 5,350 |
| Delimbing knives, number | 4 |
| Saw motor (in^3/rev) | 1.16 |
| Saw motor (cm^3/rev) | 19 |
| Max hydraulic flow (L/min) | 305 / 290 |
| Max hydraulic flow (gpm) | 80.6 / 76.6 |
| Max hydraulic pressure (psi) | 4,061 |
| Max hydraulic pressure (MPa) | 28 |
| Cutting diameter, max (in) | 23.6 |
| Cutting diameter, max (mm) | 600 |
| Head opening, max (in) | 21.7 |
| Head opening, max (mm) | 550 |
| Feed roller type | Steel |
| Height to top knife (in) | 53.9 |
| Height to top knife (mm) | 1,370 |
| Feed roller opening, max (in) | 21.7 |
| Feed roller opening, max (mm) | 550 |
| Opening front knives (mm) | 610 |
| Opening front knives (in) | 24 |
| Opening front knife to rear knife (in) | 26.6 |
| Opening front knife to rear knife (mm) | 675 |
| Delimbing diameter, tip to tip (in) | 15.7 |
| Delimbing diameter, tip to tip (mm) | 400 |
| Bar (in) | 29.5/25.2 |
| Bar (cm) | 75/64 |
