S82-1
رقم القطعة: KOMATSU-S82-1
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
S82-1
المواصفات
| Weight (kg) | 829 |
|---|---|
| Weight (lbs) | 1,828 |
| Max width (in) | 46.7 |
| Max width (mm) | 1,185 |
| Height including rotator (mm) | 1,522 |
| Height including rotator (in) | 59.9 |
| Feed speed (m/s) | 0-5 |
| Feed speed (ft/s) | 0-16.4 |
| Gross feed force (kN) | 20.3 |
| Gross feed force (lbf) | 4,564 |
| Delimbing knives, number | 4 |
| Saw motor (in^3/rev) | 1.16 |
| Saw motor (cm^3/rev) | 19 |
| Max hydraulic flow (L/min) | 240 |
| Max hydraulic flow (gpm) | 63.4 |
| Max hydraulic pressure (psi) | 4,061 |
| Max hydraulic pressure (MPa) | 28 |
| Cutting diameter, max (in) | 22.8 |
| Cutting diameter, max (mm) | 580 |
| Head opening, max (in) | 18.1 |
| Head opening, max (mm) | 460 |
| Feed roller type | Steel |
| Height to top knife (in) | 56.2 |
| Height to top knife (mm) | 1,428 |
| Feed roller opening, max (in) | 18.1 |
| Feed roller opening, max (mm) | 460 |
| Opening front knives (mm) | 517 |
| Opening front knives (in) | 20.4 |
| Opening front knife to rear knife (in) | 20.9 |
| Opening front knife to rear knife (mm) | 532 |
| Delimbing diameter, tip to tip (in) | 13.8 |
| Delimbing diameter, tip to tip (mm) | 350 |
| Bar (in) | 26.4 |
| Bar (cm) | 67 |
