Caterpillar

772 (07) Off-Highway Truck

Name: 772 (07) Off-Highway Truck
Brand: Caterpillar
SKU: CAT-122060

رقم القطعة: CAT-122060

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

772 (07) Off-Highway Truck

المواصفات

Engine Model	Cat® C18
Gross Power - SAE J1995:2014	451 kW
Net Power - SAE J1349:2011	410 kW
Bore	145 mm
Stroke	183 mm
Displacement	18.1 l
Forward - 1	12.8 km/h
Forward - 2	17.5 km/h
Forward - 3	23.7 km/h
Forward - 4	31.9 km/h
Forward - 5	43.3 km/h
Struck	23.9 m³
Forward - 6	58.4 km/h
Forward - 7	79.2 km/h
Fuel Tank	530 l
Cooling System	125 l
Front Axle - Empty	51.4 %
DEF Tank	21 l
Rear Axle - Empty	48.6 %
Model	772 (07)
Front Axle - Loaded	34.2 %
Product Page	https://www.cat.com/en_US/products/new/equipment/off-highway-trucks/off-highway-trucks/122060.html
Caterpillar Category	Off-Highway Trucks
Rear Axle - Loaded	65.8 %
Caterpillar Category Path	Products > Equipment > Off-Highway Trucks > Off-Highway Trucks > 772 (07)
Caterpillar Product Family	equipment
Caterpillar Product Page ID	122060
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20231213-48609-28487
Operating Width	4780 mm
Net Torque - SAE J1349	3012 N·m
Ground Clearance	618 mm
Net Power - ISO 9249	410 kW
Engine Power - ISO 14396	446 kW
Wheel Base	3960 mm
Number of Cylinders	6
Body Weight	8258 kg
Chassis Weight	26863 kg
Differential Ratio	2.74:1
Planetary Ratio	4.80:1
Top Speed - Loaded	79.1 km/h
Pump Flow - High Idle	425 L/min
Total Reduction Ratio	13.14:1
Relief Valve Setting - Raise	18950 kPa
Target Gross Machine Weight	82100 kg
Body Raise Time - High Idle	8 s
Brake Surface - Front	1395 cm²
Body Lower Time - Float	10 s
Brake Surface - Rear	50281 cm²
Brake Standards	ISO 3450:2011
Relief Valve Setting - Lower	3450 kPa
Crankcase	64 l
Empty Loaded Cylinder Stroke Front	234 mm
Rear axle - Oscillation	8.9 °
Empty Loaded Cylinder Stroke Rear	149 mm
Steer Angle	40.5 °
Steering Standards	ISO 5010:2007
Steering Tank	55 l
Turning Diameter - Front	17.6 m
Steering System - Including Tank	87 l
Differential - Final Drives	180 l
Turning Circle - Clearance Diameter	20.3 m
Standard Tire	21.00R33 (E4)
Brake Hoist System	227 l
Torque Converter - Transmission System	64 l
FOPS Standards	FOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II FOPS criteria.
Reverse	16.8 km/h
Height - Top of ROPS	3907 mm
Body Power Down - High Idle	10 s
Overall Body Length	8164 mm
Inside Body Length	5781 mm
Sound Standards (1)	Hearing protection may be needed when operating with open operator station & cab for extended periods or in noisy environment.
Overall Length	8808 mm
Rear Axle - Tail	2598 mm
Inside Body Depth - Maximum	1747 mm
Dump Clearance	562 mm
Overall Height - Body Raised	8257 mm
Loading Height - Empty	3570 mm
Centerline Front Tire Width	3165 mm
Engine Guard Clearance	618 mm
Outside Body Width	3931 mm
Inside Body Width	3642 mm
Centerline of Rear Dual Tire Width	2652 mm
Front Canopy Height	4159 mm
Body Capacity - SAE 2:1	31.2 m³
Overall Tire Width	3927 mm
Rear Axle - Clearance	572 mm
Sound Standards (2)	Exterior sound pressure power level for standard machine measured according to tests specified in ISO 6395:2008 is 118 dB(A).
Nominal Payload Class (100%)	46.8 t
Rated Engine Speed	1700 r/min
Maximum Payload Class (110%)	51.4 ton (US)
Target Payload Capacity	46.8 ton (US)
Not to Exceed Payload (120%)	56.1 ton (US)
Target Gross Machine Operating Weight	82100 kg
Body Capacity (SAE 2:1)**	31.2 m³
Brake/Hoist Hydraulic Tank	145 l
Sound Standards (3)	Operator Equivalent Sound Pressure Level (Leq) is 78 dB(A) when ISO 6396:2008 is used to measure the value for an enclosed cab.
Heaped 2:1 (SAE)	31.2 m³
Capacity - Flat Floor - 100% Fill Factor — Heaped 2:1 (SAE)	31.3 m³
ROPS Standards	ROPS (Rollover Protective Structure) for cab offered by Caterpillar meets ISO 3471:2008 ROPS criteria.
