John Deere

320 P-Tier Backhoe

Name: 320 P-Tier Backhoe
Brand: John Deere
SKU: JOHNDEERE-17C1T

رقم القطعة: JOHNDEERE-17C1T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

320 P-Tier Backhoe

المواصفات

Displacement	4.5 L (276 cu. in.)
Net Peak Power (ISO 9249)	84 kW (113 hp) at 1,900 rpm
Net Peak Torque (ISO 9249)	459 Nm (338 lb.-ft.) at 1,600 rpm
Gear	1 5.3 km/h (3.3 mph) 6.7 km/h (4.2 mph)
Model	320 P-Tier
Base Code	17C1T
Division	loaders
Product Family	backhoes
Weight	416 kg 405 kg 521 kg 921 kg 416 kg 405 kg 521 kg 921 kg
(11 ft.	4 in.) (11 ft. 4 in.) (11 ft. 4 in.) (11 ft. 4 in.) (11 ft. 4 in.) (11 ft. 4 in.) (11 ft. 4 in.) (11 ft. 4 in.)
(9 ft.	1 in.) (8 ft. 7 in.) (8 ft. 10 in.) (8 ft. 9 in.) (9 ft. 1 in.) (8 ft. 7 in.) (8 ft. 10 in.) (8 ft. 9 in.)
With full fuel tank;	75-kg (165 lb.) Operator, 7748 kg (17,081 lb.) 7885 kg (17,383 lb.)
With	1.06-m (3 ft. 6 in.) Extendable Dipperstick With 1.06-m (3 ft. 6 in.) Extendable Dipperstick
Width	2184 mm 2184 mm 2346 mm 2346 mm 2184 mm 2184 mm 2346 mm 2346 mm
Standard	90 mm (3.54 in.) 50 mm (1.97 in.) 500 mm (19.69 in.)
and	454-kg (1,000 lb.) Counterweight
Canopy	25.7 L (27.2 qt.) Hydraulic Reservoir 45.5 L (12.0 gal.)
Cab	27.5 L (29.1 qt.) Hydraulic System 130.2 L (34.4 gal.)
Net Torque Rise	30%
Loader	163 L/m (43 gpm)
Fuel Tank (with ground-level fueling)	128.7 L (34.0 gal.)
Gross Peak Power	86 kW (115 hp) at 1,900 rpm
Engine and	19.5L-24 Rear Tires Forward Reverse
Axle Oscillation, Stop to Stop, Front Axle	22 deg.
SAE J43	6500 kg (14,300 lb.) 7500 kg (16,500 lb.)
Dynamic	9000 kg (19,800 lb.) 10 000 kg (22,000 lb.)
Static	26 500 kg (58,400 lb.) 26 500 kg (58,400 lb.)
Ultimate	43 500 kg (95,900 lb.) 43 500 kg (95,900 lb.)
Rear Axle Loader-grip actuated, hydraulically engaged,	100% mechanical lock
With Brakes	3.53 m (11 ft. 7 in.)
Without Brakes	4.03 m (13 ft. 3 in.)
Pump Flow at	2,200 rpm
Backhoe	163 L/m (43 gpm)
Loader Boom (2)	80 mm (3.15 in.) 50 mm (1.97 in.) 789 mm (31.08 in.)
Loader Bucket (1)	90 mm (3.54 in.) 50 mm (1.97 in.) 744 mm (29.29 in.)
Backhoe Boom (1)	120 mm (4.72 in.) 56 mm (2.20 in.) 794 mm (31.26 in.)
Backhoe Crowd (1)	115 mm (4.53 in.) 63 mm (2.48 in.) 603 mm (23.72 in.)
Backhoe Bucket (1)	90 mm (3.54 in.) 56 mm (2.20 in.) 810 mm (31.89 in.)
Backhoe Swing (2)	90 mm (3.54 in.) 50 mm (1.97 in.) 278 mm (10.94 in.)
Backhoe Extendable Dipperstick (1)	70 mm (2.76 in.) 40 mm (1.57 in.) 1062 mm (41.81 in.)
MFWD (1)	65 mm (2.56 in.) 40 mm (1.57 in.) 210 mm (8.27 in.)
Torque Converter and Transmission	15.1 L (16.0 qt.) Planetary (each) 0.9 L (1.0 qt.)
ISO 6016 Operating Mass	8225 kg (18,133 lb.) 8225 kg (18,133 lb.)
ISO 6016 Gross Machinery Mass	10 000 kg (22,046 lb.) 10 000 kg (22,046 lb.)
Standard Equipment, Canopy, and	204-kg
Typical With Cab, Extendable Dipperstick,	8553 kg (18,856 lb.) 8666 kg (19,105 lb.)
Extendable Dipperstick	209 kg (461 lb.) 185 kg (408 lb.)
Front Loader Coupler	305 kg (672 lb.) 305 kg (672 lb.)
Backhoe Bucket Coupler	133 kg (293 lb.) 133 kg (293 lb.)
A Ground Clearance, Minimum	322 mm (13 in.) 322 mm (13 in.)
B Overall Length, Transport	7.48 m (24 ft. 6 in.) 7.49 m (24 ft. 7 in.)
C Width Over Tires	2.20 m (7 ft. 3 in.) 2.20 m (7 ft. 3 in.)
D Height to Top of ROPS/Cab	2.84 m (9 ft. 4 in.) 2.84 m (9 ft. 4 in.)
E Length From Axle to Axle, MFWD Axle	2.19 m (7 ft. 2 in.) 2.19 m (7 ft. 2 in.)
Backhoe specifications are with	610-mm x 0.21-m (24 in. x 7.5 cu. ft.) bucket; dipper lift specs are with a boom angle of 65 deg.
Bucket Range	305–610 mm (12–24 in.) 305–610 mm (12–24 in.)
Swing Arc	180 deg. 180 deg.
F Loading Height, Truck Loading Position	3.42 m (11 ft. 3 in.) 3.56 m (11 ft. 8 in.) 4.18 m (13 ft. 9 in.) 3.58 m (11 ft. 9 in.) 3.56 m (11 ft. 8 in.) 4.18 m (13 ft. 9 in.)
G Reach From Center of Swing Pivot	5.52 m (18 ft. 1 in.) 5.62 m (18 ft. 5 in.) 6.63 m (21 ft. 9 in.) 5.68 m (18 ft. 8 in.) 5.63 m (18 ft. 5 in.) 6.61 m (21 ft. 8 in.)
H Reach From Center of Rear Axle	6.59 m (21 ft. 7 in.) 6.68 m (21 ft. 11 in.) 7.69 m (25 ft. 3 in.) 6.75 m (22 ft. 2 in.) 6.69 m (21 ft. 11 in.) 7.67 m (25 ft. 2 in.)
I Digging Depth (SAE maximum)	4.33 m (14 ft. 3 in.) 4.48 m (14 ft. 8 in.) 5.53 m (18 ft. 2 in.) 4.65 m (15 ft. 3 in.) 4.58 m (15 ft. 0 in.) 5.59 m (18 ft. 4 in.)
610-mm (2 ft.) Flat Bottom	4.30 m (14 ft. 1 in.) 4.44 m (14 ft. 7 in.) 5.49 m (18 ft. 0 in.) 4.60 m (15 ft. 1 in.) 4.54 m (14 ft. 11 in.) 5.55 m (18 ft. 2 in.)
2440-mm (8 ft.) Flat Bottom	3.97 m (13 ft. 0 in.) 4.11 m (13 ft. 6 in.) 5.24 m (17 ft. 2 in.) 4.31 m (14 ft. 2 in.) 4.24 m (13 ft. 11 in.) 5.34 m (17 ft. 6 in.)
Standard Stabilizers	2.25 m (7 ft. 5 in.) 2.25 m (7 ft. 5 in.) 2.25 m (7 ft. 5 in.) — — —
Extended Stabilizers	2.42 m (7 ft. 11 in.) 2.42 m (7 ft. 11 in.) 2.42 m (7 ft. 11 in.) — — —
N Bucket Rotation	190 deg. 190 deg. 190 deg. 190 deg. 190 deg. 190 deg.
O Transport Height	3.50 m (11 ft. 6 in.) 3.51 m (11 ft. 6 in.) 3.51 m (11 ft. 6 in.) 3.50 m (11 ft. 6 in.) 3.50 m (11 ft. 6 in.) 3.50 m (11 ft. 6 in.)
P Bucket Dump Angle, Maximum	45 deg. 45 deg.
Q Rollback Angle at Ground Level	40 deg. 40 deg.
Bucket Capacity	0.86 m 1.00 m 1.06 m 1.01 m 0.86 m 1.00 m 1.06 m 1.01 m
Lift Capacity, Full Height	3541 kg 3244 kg 3489 kg 2973 kg 3603 kg 3300 kg 3527 kg 2973 kg
R Height to Bucket Hinge Pin, Maximum	3.46 m 3.46 m 3.46 m 3.46 m 3.46 m 3.46 m 3.46 m 3.46 m
S Dump Clearance, Bucket at	45 deg. 2.76 m 2.62 m 2.70 m 2.67 m 2.76 m 2.62 m 2.70 m 2.67 m
T Reach at Full Height, Bucket at	45 deg. 769 mm 912 mm 765 mm 799 mm 769 mm 912 mm 765 mm 799 mm
Hydraulic Capacity	1219-mm (48 in.) Tines 1524-mm (60 in.) Tines
A Maximum Height	2081 kg (4,587 lb.) 1928 kg (4,251 lb.)
B Maximum Reach	3188 kg (7,029 lb.) 3016 kg (6,649 lb.)
C At Ground Line	4095 kg (9,029 lb.) 3865 kg (8,521 lb.)
D Below Ground Line	156 mm (6.1 in.) 156 mm (6.1 in.)
Lift capacities are over-end values in kg (lb.). Figures listed are	100% of the maximum lift force available.
Manufacturer and Model John Deere PowerTech™ EWL	4.5L 4045HL052 turbocharged
Torque Converter Single stage, dual phase with 2.63:1 stall ratio,	280 mm (11 in.)
Rear Axle	18.0 L (19.0 qt.) MFWD Axle
Engine Oil (including vertical spin-on filter)	13.0 L (13.7 qt.) Differential Housing 6.5 L (6.9 qt.)
Lift Mode	27 579 kPa (4,000 psi)
Heavy-Lift (HL) Option	125 mm (4.92 in.) 63 mm (2.48 in.) 887 mm (34.92 in.)
HL Option	120 mm (4.72 in.) 63 mm (2.48 in.) 591 mm (23.27 in.)
Heavy-Duty Option	100 mm (3.94 in.) 63 mm (2.48 in.) 810 mm (31.89 in.)
Extended	100 mm (3.94 in.) 50 mm (1.97 in.) 500 mm (19.69 in.)
HL Option Extended	100 mm (3.94 in.) 50 mm (1.97 in.) 500 mm (19.69 in.)
With MFWD 12.5/80-18 R4 (10)	19.5L-24 R4 (12)
Cooling System Diesel Exhaust Fluid (DEF) Tank	13.7 L (3.6 gal.)
K Stabilizer Width, Transport With Standard Pads, — — —	2.35 m (7 ft. 8 in.) 2.35 m (7 ft. 8 in.) 2.35 m (7 ft. 8 in.)
L Stabilizer Spread, Operating — — —	3.45 m (11 ft. 4 in.) 3.45 m (11 ft. 4 in.) 3.45 m (11 ft. 4 in.)
M Stabilizer Overall Width, Operating — — —	4.03 m (13 ft. 3 in.) 4.03 m (13 ft. 3 in.) 4.03 m (13 ft. 3 in.)
U Digging Depth Below Ground, Bucket Level	89 mm 89 mm 134 mm 129 mm 89 mm 89 mm 134 mm 129 mm
V Length From Front Axle Centerline to Bucket	1.96 m 2.16 m 2.03 m 2.08 m 1.96 m 2.16 m 2.03 m 2.08 m
Cutting Edge (6 ft.	5 in.) (7 ft. 1 in.) (6 ft. 8 in.) (6 ft. 10 in.) (6 ft. 5 in.) (7 ft. 1 in.) (6 ft. 8 in.) (6 ft. 10 in.)
A 5630 kg (12,412 lb.)	5630 kg (12,412 lb.) 4989 kg (10,998 lb.) 4989 kg (10,998 lb.) 3784 kg (8,341 lb.) 4199 kg (9,257 lb.)
B 4701 kg (10,365 lb.)	4701 kg (10,365 lb.) 3552 kg (7,831 lb.) 3552 kg (7,831 lb.) 2729 kg (6,016 lb.) 3033 kg (6,686 lb.)
C 3550 kg (7,826 lb.)	3550 kg (7,826 lb.) 3185 kg (7,022 lb.) 3185 kg (7,022 lb.) 2411 kg (5,316 lb.) 2639 kg (5,817 lb.)
D 3222 kg (7,104 lb.)	3222 kg (7,104 lb.) 3121 kg (6,881 lb.) 3121 kg (6,881 lb.) 2280 kg (5,028 lb.) 2396 kg (5,282 lb.)
E 3167 kg (6,981 lb.)	3167 kg (6,981 lb.) 3165 kg (6,978 lb.) 3295 kg (7,265 lb.) 2203 kg (4,857 lb.) 2288 kg (5,044 lb.)
F 3096 kg (6,826 lb.)	3330 kg (7,341 lb.) 1387 kg (3,057 lb.) 1565 kg (3,451 lb.) 2136 kg (4,710 lb.) 2267 kg (4,998 lb.)
G 1473 kg (3,247 lb.)	1647 kg (3,631 lb.) 1721 kg (3,795 lb.) 1943 kg (4,284 lb.) 2047 kg (4,512 lb.) 2278 kg (5,023 lb.)
H 1804 kg (3,976 lb.)	2019 kg (4,451 lb.) 1818 kg (4,007 lb.) 2053 kg (4,527 lb.) 1883 kg (4,151 lb.) 2097 kg (4,623 lb.)
I 1910 kg (4,211 lb.)	2140 kg (4,717 lb.) 1842 kg (4,060 lb.) 2083 kg (4,591 lb.) 954 kg (2,103 lb.) 1082 kg (2,385 lb.)
J 1944 kg (4,286 lb.)	2180 kg (4,806 lb.) 1836 kg (4,049 lb.) 2079 kg (4,584 lb.) 1206 kg (2,659 lb.) 1366 kg (3,010 lb.)
K 1948 kg (4,294 lb.)	2186 kg (4,820 lb.) 1819 kg (4,009 lb.) 2061 kg (4,544 lb.) 1323 kg (2,917 lb.) 1498 kg (3,302 lb.)
L 1938 kg (4,272 lb.)	2177 kg (4,799 lb.) 1796 kg (3,960 lb.) 2038 kg (4,494 lb.) 1383 kg (3,050 lb.) 1567 kg (3,454 lb.)
M 1922 kg (4,238 lb.)	2161 kg (4,765 lb.) 1774 kg (3,911 lb.) 2016 kg (4,444 lb.) 1415 kg (3,119 lb.) 1603 kg (3,535 lb.)
N 1907 kg (4,203 lb.)	2146 kg (4,730 lb.) 1756 kg (3,872 lb.) 1998 kg (4,405 lb.) 1430 kg (3,153 lb.) 1622 kg (3,576 lb.)
O 1895 kg (4,177 lb.)	2134 kg (4,705 lb.) 1747 kg (3,851 lb.) 1990 kg (4,387 lb.) 1437 kg (3,167 lb.) 1631 kg (3,596 lb.)
P 1891 kg (4,169 lb.)	2132 kg (4,701 lb.) 1753 kg (3,865 lb.) 1999 kg (4,407 lb.) 1439 kg (3,171 lb.) 1635 kg (3,604 lb.)
Q 1903 kg (4,196 lb.)	2148 kg (4,735 lb.) 1791 kg (3,949 lb.) 2045 kg (4,509 lb.) 1439 kg (3,172 lb.) 1637 kg (3,608 lb.)
R 1948 kg (4,294 lb.)	2200 kg (4,851 lb.) 1926 kg (4,245 lb.) 2201 kg (4,852 lb.) 1440 kg (3,175 lb.) 1639 kg (3,614 lb.)
S 2085 kg (4,596 lb.)	2358 kg (5,198 lb.) 2142 kg (4,722 lb.) 2449 kg (5,400 lb.) 1445 kg (3,185 lb.) 1646 kg (3,629 lb.)
T 3285 kg (7,243 lb.)	3724 kg (8,210 lb.) — — 1456 kg (3,210 lb.) 1661 kg (3,661 lb.)
U — — — —	1480 kg (3,262 lb.) 1689 kg (3,724 lb.)
V — — — —	1526 kg (3,365 lb.) 1744 kg (3,845 lb.)
W — — — —	1628 kg (3,590 lb.) 1862 kg (4,105 lb.)
X — — — —	1954 kg (4,309 lb.) 2235 kg (4,927 lb.)
Y — — — —	2950 kg (6,503 lb.) 3370 kg (7,429 lb.)
noted, these specifications are based on a 320 P-Tier unit with	19.5L-24-in. 12PR (R4) tubeless rear and 12.5-80/18 10PR (R4) front tires, and 1.06-m (1.39 cu. yd.)
