PC400HD-8
رقم القطعة: KOMATSU-PC400HD-8
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
PC400HD-8
المواصفات
| Gradeability | 70%, 35 degrees |
|---|---|
| Operating weight (kg) | 44 000 |
| Operating weight (lbs) | 97 004 |
| Engine model | Komatsu SAA6D125E-5 |
| Aspiration | Turbocharged, aftercooled |
| Number of cylinders | 6 |
| Piston displacement (L) | 11.04 |
| Fuel tank (US gal) | 171.7 |
| Fuel tank (L) | 650 |
| Final drive (US gal) | 2.8 |
| Final drive (L) | 10.5 |
| Hydraulic tank (L) | 248 |
| Hydraulic tank (US gal) | 65.5 |
| Pumps for | Boom, arm, attachment, swing and travel circuit |
| Maximum flow (US gpm) | 182 |
| Maximum flow (L/min) | 690 |
| Travel | 2 x axial piston motor with parking brake |
| Swing | 1 x axial piston motor with swing holding brake |
| Maximum drawbar pull (lbs) | 74 187 |
| Parking brake | Mechanical disc brake |
| High (mph) | 3.4 |
| High (kph) | 5.5 |
| Engine (L) | 37 |
| Engine (US gal) | 9.8 |
| Center frame | X-frame |
| Track frame | Box-section |
| Power (HP) | 362 (gross) @ 1950 rpm |
| Power (kW) | 270 (gross) @ 1950 rpm |
| Drive method | Hydrostatic |
| Service brake | Hydraulic lock |
| Swing torque (kg-m) | 13 414 |
| Swing torque (ft-lbs) | 82 313 |
| Piston displacement (in³) | 673.7 |
| Swing drive (L) | 20 |
| Swing drive (US gal) | 5.3 |
| Hydraulics type | HydrauMind |
| Hydraulic type | Two-variable displacement piston type |
| Steering control | Two levers with pedals |
| Maximum drawbar pull | 330 kN |
| Engine type | Water-cooled, 4-cycle, direct injection |
| Minimum width (in) | 145.7 |
| Minimum width (mm) | 3 700 |
| Height of cabin (mm) | 3 900 |
| Height of cabin (in) | 153.5 |
| Road clearance (mm) | 780 |
| Road clearance (in) | 30.7 |
