Warman® 5000 Vertical Cantilever Sump Pump

Name: Warman® 5000 Vertical Cantilever Sump Pump
Brand: Weir

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The Warman® 5000 series of vertical centrifugal sump pumps (Service Class 1-3) are recognised worldwide for their reliability in severe-duty applications - especially those involving chemicals, flue gas desulfurisation (FGD), phosphate or hard rock. Formerly branded Galigher, these cantilever pumps have been commercialised under the Warman brand since 2012. Our wide selection of construction materials - from natural rubbers to titanium - ensures flexibility and reliability in abrasive and corrosive applications, making these models ideal vertical chemical pumps. Warman® 5000 pumps are easily identified by their unique long shaft design, known in the industry as the Galigher-style pump. They also have four signature column supports for the casing making them very robust and more resistant to fatigue compared to other similarly sized pumps. Compared to other vertical sump pumps, Warman® 5000 cantilever pumps offer the following benefits: A robust, heavy-duty, double-volute construction that offers long service life and easy maintenance A wide range of severe-duty material options Can be rubber-lined or all-metal depending on the application Zero ancillary water costs Reduced risk of blockages For more information about our range of Warman® vertical pumps, please get in touch with our team.

المواصفات

TEMPERATURE RANGE	From 1 to 90°C
CAPACITY	Capacities up to 8,000 gpm (1,817 m3/hr)
Brand line	Warman®
Product type	Pumps, Vertical Chemical Pumps, Vertical Pumps, Vertical Slurry Pumps
Catalogue category	Vertical Chemical Pumps, Vertical Sump Pumps, Vertical Slurry Pumps, Pumps
SIZE RANGE	Discharge sizes: From 40mm to 300mm (1.5" to 12")
PRESSURE CLASS	Heads to 170ft (52m) \| Pressures to 109 psi (750 kPa)
MATERIAL	To match your processing requirements, Warman® 5000 pumps have elastomer wear component options including natural rubbers, neoprene, urethane, butyl, EPDM and others. Metal wear component options include Ultrachrome® A05 chrome iron, stainless steel and super duplex stainless steel, and white and grey cast irons.
DESIGN STANDARDS	Hydraulic Institute 9.6.2, ISO 9001, OHSAS 18001
