Warman® HTP High Pressure Pumps

Name: Warman® HTP High Pressure Pumps
Brand: Weir

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Rated to the highest of pressures, our large Warman® HTP high-pressure centrifugal pumps are designed specifically for severe multi-stage and long-distance pumping applications. Drawing on years of proven field experience, these horizontal multistage hydrotransport and tailings pumps centrifugal pumps have become renowned for their safety, long wear life, reliability and ease of maintenance . They also provide an efficient and durable solution to long-distance hydrotransport and tailings duties. Warman® HTP high-pressure pumps have become one of the industry’s most cost-effective pumping solutions for demanding high-pressure slurry services (Class 4) and established themselves as the dominant pump within the Canadian oil sands industry. The Warman® HTP pumps range consists of the HT model (designed for low-pressure applications), HTP model (designed for standard-pressure applications ) and the HTPP model (designed for high-pressure applications). Warman® HTP pumps come fully metal- or rubber-lined, with a range of features including: An advanced hydraulic design A wide range of material options An enhanced Warman® mechanical end, and The proven Warman® double-wall construction For more information about Warman® high-pressure centrifugal pumps , please get in touch with our team.

المواصفات

TEMPERATURE RANGE	1 to 90°C
CAPACITY	Capacities to 55,000 gpm (12,500 m3/hr)
Brand line	Warman®
Product type	Horizontal Slurry Pumps, Hydrotransport and Tailings Pumps, Pumps
Catalogue category	Hydrotransport and Tailings Pumps, Horizontal Centrifugal Slurry Pumps, Pumps
SIZE RANGE	Discharge sizes - 500mm to 650mm (20" - 26")
PRESSURE CLASS	Pressures to 1058 psi (7,300 kPa)
MATERIAL	Warman® HTP high-pressure pumps contain a ductile iron outer casing with a metal impeller, metal volute liners, and metal or rubber throatbush and frame plate liner insert.
DESIGN STANDARDS	Our Warman® HTP pumps are designed in accordance with ANSI/HI 12.1-12.6 (2016), and our Madison facility is ISO 9001/14001/18001 certified.
