WARMAN® mill circuit pumps (MCR²®, MCR®, MCR®-M, MCU®)

Weir

WARMAN® mill circuit pumps (MCR²®, MCR®, MCR®-M, MCU®)

Name: WARMAN® mill circuit pumps (MCR²®, MCR®, MCR®-M, MCU®)
Brand: Weir

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Able to process large particles in highly abrasive slurries, WARMAN® mill circuit (MC) pumps are specifically designed for severe mill circuit duties and aggressive slurry applications (Service Class 3 & 4). These types of horizontal centrifugal slurry pumps are renowned for their performance with ball and SAG mill discharge and cyclone feed applications in mineral processing plants. Today, the WARMAN® MCR²® mill duty pump represents the latest generation of this technology leadership , extending the performance, wear life and reliability that have made WARMAN® MC pump series the industry benchmark. Compared to other mill circuit pumps, WARMAN® MC pumps offer the following benefits: Hydraulics are based on more than 30 years of fundamental and applied research including various wear performance field trials Superior reliability, performance and wear life due to their advanced hypereutectic alloy and elastomer technology, unique design and wear evaluation software A flexible design that comes in a variety of sizes and has lined or unlined options available Large, open internal passages and expelling vanes that improve flow within the pump and reduce internal velocities and wear Features a reversible casing (open back design) that allows the discharge orientation to be positioned either right vertical (standard Clock Wise - CW) or left vertical (Counter Clock Wise - CCW) providing greater layout flexibility The two-piece cover plate provides easy access to the pump internals for replacement of the impeller and throatbush The low flow design stuffing box improves packing life and decreases gland seal water consumption by up to 50% Their quick wet-end change-out helps to reduce mill downtime Made with the latest wear-resistant material technology which results in increased pump wear life In addition to the above, WARMAN® mill pumps feature: A large-diameter, low-speed, high-efficiency impeller, manufactured from a wide range of abrasion-resistant alloys Heavy-duty roller bearings housed in a low-profile fixed assembly (or a removable bearing cartridge) Patented shrouds that extend past the periphery of the impeller Increased throatbush adjustment with the WARMAN® XA throatbush For more information about WARMAN® mill discharge pumps, get in touch with our team.

المواصفات

TEMPERATURE RANGE	1 to 100°C
CAPACITY	Capacities to 55,000 gpm (12,500 m3/hr)
Brand line	Warman®
Product type	Pumps
Catalogue category	Horizontal Centrifugal Slurry Pumps, Pumps
SIZE RANGE	Discharge sizes - 125mm to 760mm (5” to 30”)
PRESSURE CLASS	Heads to 180 ft (55m) \| Pressures to 130 psi (900 kPa)
MATERIAL	Lined WARMAN® mill discharge pumps contain a ductile iron outer casing with metal impeller, throatbush and frame plate liner insert. The internal liners will depend on the model chosen. Unlined designs allow for a metal casing.
DESIGN STANDARDS	Hydraulic Institute 6, ISO 9001, ISO 14001, OHSAS 18001 and CE certified
